Dragon 1500 V2
Highlite International B.V. Vestastraat 6468 EX Kerkrade the Netherlands –2 – – –
Ordercode: 61102
MANUAL
ENGLISH
1
Ordercode: 61102
Dragon 1500
Table of contents
Warning ............................................................................................................................................................................... 2
Safety Instructions ......................................................................................................................................................... 2
Operating Determinations .......................................................................................................................................... 4
Rigging ............................................................................................................................................................................ 4
Return Procedure .......................................................................................................................................................... 5
Claims .............................................................................................................................................................................. 5
Description of the device ................................................................................................................................................. 6
Frontside 6..........................................................................................................................................................................
Backside 7.........................................................................................................................................................................
Installation ........................................................................................................................................................................... 7
Set Up and Operation ....................................................................................................................................................... 8
Remote control operation .......................................................................................................................................... 8
Maintenance ...................................................................................................................................................................... 9
Replacing a Fuse .......................................................................................................................................................... 9
Troubleshooting ...............................................................................................................................................................10
Product Specification .....................................................................................................................................................10
Dimensions ........................................................................................................................................................................11
Notes ..................................................................................................................................................................................12
2
Ordercode: 61102
Dragon 1500
Warning
Unpacking Instructions
Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be
returned to the factory, it is important that the fixture be returned in the original factory box and packing.
Your shipment includes:
● Dragon 15 00
● Detachable on/off remote control
(cable length: 5 m)
● IEC power cable (1,5 m)
● User manual
Safety Instructions
Every person involved with the installation, operation and maintenance of this device has to:
● be qualified
● follow the instructions of this manual
Before your initial start-up, please make sure that there is no damage caused by transportation. Should
there be any, consult your dealer and do not the device.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes written in this manual.
Please consider that damages caused by manual modifications to the device are not subject to
warranty.
This device contains no user-serviceable parts. Refer servicing to qualified technicians only.
