Sida 1/12
Dragon S100 V1
Highlite International B.V. – – – – Vestastraat 2 6468 EX Kerkrade the Netherlands
Ordercode: 61110
MANUAL
ENGLISH
Ordercode: 61110
Dragon S100
Table of contents
Warning ............................................................................................................................................................................... 2
Safety Instructions ......................................................................................................................................................... 2
Operating Determinations .......................................................................................................................................... 4
Rigging ............................................................................................................................................................................ 4
Connection with the mains......................................................................................................................................... 4
Return Procedure .......................................................................................................................................................... 5
Claims .............................................................................................................................................................................. 5
Description of the device ................................................................................................................................................. 6
Features .......................................................................................................................................................................... 6
Frontside.......................................................................................................................................................................... 6
Backside ......................................................................................................................................................................... 7
Installation ........................................................................................................................................................................... 7
Set Up and Operation ....................................................................................................................................................... 8
Maintenance ...................................................................................................................................................................... 8
Replacing a Fuse .......................................................................................................................................................... 8
Troubleshooting ................................................................................................................................................................. 9
Product Specification ....................................................................................................................................................... 9
Dimensions ........................................................................................................................................................................10
1
Ordercode: 61110
Dragon S100
Warning
Unpacking Instructions
Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be
returned to the factory, it is important that the fixture be returned in the original factory box and packing.
Your shipment includes:
• Dragon S100
• Not detachable on/off remote control (cable
length: 3,3 m)
• IEC power cable (1,5 m)
• User manual
Safety Instructions
Every person involved with the installation, operation and maintenance of this device has to:
• b e qualified
• follow the instructions of this manual
Before your initial start up, please make sure that there is no damage caused by transportation.- Should
there be any, consult your dealer and do not the device.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes written in this manual.
Please consider that damages caused by manual modifications to the device are not subject to
warranty.
This device contains no user serviceable parts. Refer servicing to qualified technicians only.-
2
