545SD -- Vocal Microphone

General Description

The Model 545SD is a dual-impedance, unidirec-

tional, dynamic microphone. Shipped connected

for low-impedance operation, it features a silent

magnetic reed on/off switch.

The Classic Unidyne is a favorite for instrument

pickup and recording,and can be used on

lecterns for public address systems such as

those used in political conventions and legisla-

tures, convention halls, hotels, public auditori-

ums, stadiums, schools, and churches.

Features

•Exceptionally uniform cardioid pattern minimizes feedback in PA applications

•Selectable dual-impedance operation

•Silent magnetic reed on/off switch with lock option

•Cardioid dynamic

•Frequency response: 50 to 15,000 Hz

Connections

When using the microphone with a balanced input, pins 2 and 3 are the audio signal carriers. When using the mi

crophone with an unbalanced input, use a cable wired with pin 2 as the signal carrier and pin 3 connected to the

cable shield (ground), such as the Shure C20AHZ high-impedance cable.

Shure Incorporated

2/5

Impedance Selection

The microphone is shipped connected for low impedance operation. To change to high impedance, proceed as fol

lows:

1. Remove plug element at receptacle end of microphone by turning slotted setscrew in (counterclockwise) and

carefully withdrawing plug element from case.

2. Disconnect 2-terminal impedance selection socket from rear of plug element.

3. Reconnect 2-terminal impedance selection socket in reverse position so that pin 3 of plug element is inserted

in socket terminal "H" (White).

4. Reassemble plug element into microphone and seal setscrew securely by turning out (clockwise).

IMPEDANCE SELECTION RECEPTACLE END OF MICROPHONE

Polarity

All cables and microphones should be tested to ensure that they have the same polarity. To test two microphones

and/or their cables for proper polarity, connect them to an amplifier and talk or sing into them while holding them

three or four inches apart. The sound from the speakers should be the same when talking into either microphone

or directly between them. If the sound drops drastically, or if a dead spot is found when talking between the two mi

crophones, either the microphones or their cables have opposite polarity.

To change the polarity of a microphone cable, either use a Shure A15PRS phase reverser or interchange the wires

connected to pins 2 and 3 of the threepin connector at one end of the cable. To change the polarity of a micro

phone, the microphone cartridge leads must be interchanged. This should be performed by your dealer, the Shure

Factory Service Department, or other qualified service personnel.

Specifications

Type

Dynamic (moving coil)

Frequency Response

50 to 15,000 Hz

Shure Incorporated

3/5

Impedance

Dual. Microphone rating impedance is 150 ohms (250 ohms actual) for connection to microphone inputs rated at

19 to 300 ohms and 'High' for connection to highimpedance microphone inputs. Wired for low impedance as sup

plied. To change impedance, see sections on Impedance Selection and Connections.

Output Level

Open Circuit Voltage , at 1kHz

L -58.0 (1.3 dB mV

H -35.0 (17.6 dB mV

Polarity

Positive pressure on diaphragm produces positive voltage on pin 2 with respect to pin 3

Switch

Built-in magnetic reed on/off switch with lockplate. To lock switch in the ON position, remove screw on lockplate

and turn lockplate 180°. Reassemble and tighten screw.

Cartridge Shock Mount

Internal rubber vibration isolator

Swivel Adapter

Positive action, adjustable through 90° from vertical to horizontal, permits easy removal for handheld use, suitable

for mounting on stand with 5/8 in.-27 thread

Housing

Chrome-plated die casting with ARMO-DUR grille and stainless steel screen

Net Weight

less cable

255 (9oz.) g

[1]
