A120S -- Talk Switch
General Description
The A120S Accessory in-Line Switch can be used
to add an On/OFF, Push-To-Talk, Cough Button,
or Transmitter-Relay Keying function to a micro-
phone or other device rated at up to 3 amps ac
(0.5 Adc) 125V, non-inductive load. The switch
has gold-plated contacts for reliable performance
even in low-current circuits. The switch is a dou-
ty. Its push button combines with a rotary knob to
provide either spring-return momentary or lock-
ing action.
The unit is supplied with a crimp-on strain relief
tor 6.4mm (0.25-in.) diameter cable and with a flex
relief for either large or small diameter cables.
The permanently attached belt clip can be rotated
on the case to any of four positions for the most
convenience in use.
Operation
Shure Incorporated
2/5
Switch Function Rotary Knob Position
On/Off (Button remains down until depressed a sec
ond time)
Locking
PushToTalk (Button remains down only while de
pressed)
Momentary
Locking the Switch Button Down
The switch button can be locked down by following these steps:
1. Turn the rotary knob to Locking.
2. Press the switch button down.
3. Turn the knob to Momentary.
The button will remain locked down until the knob is returned to locking and the button is depressed again.
Switch Installation and Wiring
1. For thicker cable (e.g., one 6.4 mm [0.25 in.] diameter cable or two 3.8 mm [0.15 in.] diameter cables), cut off
the bottom of the flex relief at the rib. For narrower cable (e.g., one 2.3 mm [0.39 in.] diameter cable), use the
entire flex relief as supplied. Thread the cable(s) through the flex relief.
2. For one 6.4 mm diameter cable (0.25 in.), crimp the strain relief to the cable making sure the eyelet is toward
the raw end of the cable. Leave enough raw cable above the strain relief to permit soldering the individual con
ductors to the switch terminals.
For all other cables, loosely knot the cable above the flex relief to form a strain relief. Leave enough raw cable
above the knot to permit soldering the individual conductors to the switch terminals.
3. Solder the conductors to the switch terminals to obtain the desired function (see Figure 3 for switch configura
tion.) Take care not to leave long bare conductors that may bridge across terminals and make unintended con
nections.
When the switch is used to make connections in the middle of a cable run, it is very important to preserve conti
nuity in the cable shield. If a splice is necessary for this, be sure it is insulated from other terminals, or you may
employ an unused switch terminal to make the connection. Leaving the shield discontinuous may cause unde
sirable hum in a circuit.
4. Assemble the switch by inserting the tab on the bottom back of the switch into the slot in the upper case front.
(See Figure 4)
5. Insert the flange in the flex relief into the slot between the case bottom and the small horizontal projection.
6. If the strain relief is used, align its hole with the hole in the center boss in the lower case front. Align the cable
to one side of the boss.
If the cable is knotted to provide a strain relief, the center boss in the case may be inserted through the center
of the knot with the cable lying to the side of the boss.
