GeneralDescription

TheAXT620EthernetSwitchisarugged,rack-mountable9-portswitchthat

simplifiesthenetworkingofShuresystemsandminimizesnetworkconfigu-

rationsetup.ItisequippedwithPoweroverEthernet(PoE)portsforenabled

devicesandaDHCPservertoautomaticallyassignIPaddressestocompo-

nents.

Features

•Rugged1RUconstruction

•Internalpowersupply

•8rearpanelports,4ofwhichhavePoweroverEthernet(PoE)

•Frontpanelport

•On-boardDHCPserver

•Easysystemintegration

FrontandRearPanel

POWER

AXT620

Ethernet

Switch

LINK

LINK

LINK

10/100Mb

10/10010/100 & PoE

100Mb

100Mb

PoE

12345678

ON

OFF

DHCP

1

2

3

4

Model Name: SHURE AXT620

MAC: 0011FC059C60

S/N: 65770110100015

LINK

10/100 Ethernet

100Mb

1234

5678

LINK

PoE

10/100 Ethernet W/PoE

RESET

Input: 100-240 V~ 50/60Hz 2A max.

5

6

9

7

8

AXT620 Ethernet Switch

Made in Taiwan

①RJ-45Ports

One10/100N-wayauto-sensingfor10Base-Tor100Base-TXconnections.

②FrontPanelLEDIndicators

Link

•Green:Connectedtonetwork

•Blinking:Networkingisactive

•Off:Notconnectedtonetwork

100Mb

•Amber:Theportisoperatingatspeedof100Mb

•Off:Theportisdisconnectedornotoperatingatspeedof100Mb

PoE

•Amber:TheportissupplingpowertotheconnectedPoEdevice

•Off:Nopowereddeviceattached

③SwitchDHCP

TurnstheDHCPserverONorOFF(Leftside=On,Rightside=Off)

④Power

•Green:Poweron

•Off:NoACpowerapplied

⑤Powercordsocket

TheswitchwillworkwithACinthevoltagerangeofAC100-240Vwithfrequencyof50-60Hz.

⑥RJ-45Ports

Eight10/100N-wayauto-sensingfor10Base-Tor100Base-TXconnections.Ports5-8alsocansupplypoweroverEthernettoenabled-devices.

⑦RearPanelLEDIndicators

Link(port1~8)

•Green:Connectedtonetwork

•Blinking:Networkingisactive

•Off:Notconnectedtonetwork

1/9©2017ShureIncorporated
