KSM9

27C3192 (Rev. 2)

KSM9

Printed in USA

Manual do Usuário

User Guide

Le Guide de l’Utilisateur

Guia del Usuario

Guida dell’Utente

Bedienungsanleitung

Руководство

пользователя

取扱説明書

사용자 안내서

用户指南

KSM9

Thank you for selecting the KSM series from Shure.

Over 85 years of audio experience has contributed to making this one of the finest

microphones available.

If you have any questions not answered in this guide, please contact Shure Applications Engineering at

847-600-8440, Monday through Friday, from 8:00 am to 4:30 pm, CST. In Europe, call 49-7262-92490.

In Asia, call 852-2893-4290. Our web address is www.shure.com.

SHURE INCORPORATED

Features

• Dual 3/4" gold layered, low-mass Mylar

diaphragms provide superior frequency

response and proximity control

• Dual polar patterns (cardioid and

supercardioid) for maximum flexibility in a

wide variety of performance applications

• Class A, discrete, transformerless

preamplifier for transparency, extremely

fast transient response and no crossover

distortion, while minimizing harmonic and

inter-modulation distortions

• Advanced suspension shock mount system

that isolates cartridge from handling and

stand noise

• Subsonic filter eliminates rumble from

mechanical vibration below 17 Hz

• Premium electronic components, including

gold-plated internal and external connectors

• Integrated three-stage "pop" protection grille

reduces plosives, wind, and other breath

noise

Performance Characteristics

• Extremely uniform polar response

• Extended frequency response

• Minimal self-noise

• Exceptional low-frequency reproduction

• Able to withstand high SPLs

• High output level

• No crossover distortion

• Superior common-mode rejection and

suppression of radio frequency interference

(RFI)

Model Variations

The KSM9 series consists of two models fea-

turing unique, switchable polar patterns and a

variety of finishes.

KSM9HS: Features hypercardioid and subcar-

dioid polar patterns with a black finish.

KSM9: Features cardioid and supercardioid

polar patterns with a charcoal-gray or cham-

pagne finish.

Applications

The KSM9 is designed to capture and control

the detailed sonic nuances of critical studio

performance, while withstanding the punish-

ment of professional live sound reinforcement.

The frequency response of the two patterns are

nearly identical, allowing performers to easily

adapt to any venue.

The cardioid pick-up pattern is ideal in live

performances for musicians with in-ear moni-

tors, providing a warm, full sound. This setting

provides excellent gain before feedback, with

minimal off-axis coloration.

The supercardioid pick-up pattern provides

maximum sound isolation and is ideal for ap-

plications in which there are high levels of

ambient noise, or where multiple instruments or

vocalists are close together.

General Description

Consistent with legendary Shure microphone

innovation, the KSM9 is the first handheld con-

denser with dual diaphragms and variable polar

patterns. As a premium vocal microphone, the

KSM9 captures vocal subtlety with extraordi-

nary detail to deliver clear articulation, func-

tional flexibility and precise vocal reproduction

for live performance. Transformerless, Class

A preamplifier circuitry and dual, gold-layered

diaphragms capture a transparent sound, re-

vealing every nuance and subtlety in a vocal

performance. The KSM9 uses an advanced

suspension shock mount to virtually eliminate

handling noise even in the most demanding live

environments.

Produktspecifikationer

Varumärke:	Shure
Kategori:	mikrofon
Modell:	KSM9
Vikt:	680 g
Bredd:	1702 mm
Förpackningens vikt:	1202 g
Förpackningens bredd:	1067 mm
Djuppackning:	165 mm
Förpackningshöjd:	165 mm
Modell:	Studiomikrofon
Längd:	254 mm
Impedans:	300 Ohm
Frekvensband som stöds:	FM
FM-band:	88 - 108 MHz
Mikrofonfrekvens:	50 - 20000 hz
Antal element:	2
Produktens färg:	Guld
Mikrofonvikt:	300 g
Anslutningsteknologi:	Kabel
Mikrofon känslighet (utnivå):	22 dB
