GENERAL

The VP64A and VP64AL are high-output omnidirectional

handheld dynamic microphones designed for professional

audio and video production. They combine exceptional per-

formance and comfortable feel with a handsome on-camera

appearance.

The VP64A and VP64AL are identical except for handle

length. The 200 mm (7-

inch) long VP64A is ideal for

closeup use and can be used outside as well as indoors.

The VP64AL is well-suited to location interviews, sports

broadcasting, and other situations where the 244 mm (9-

inch) length is an advantage.

The omnidirectional pickup pattern provides uniform pick-

up on or off axis, eliminating the need for critical microphone

positioning. The VP64A microphones also feature a tailored

frequency response with an upper midrange presence rise

that adds crispness and clarity to speech. The cartridge uti-

lizes a neodymium magnet for higher output and increased

signal-to-noise ratio.

An internal rubber isolation mount protects the micro-

phone cartridge and minimizes handling noise. A water-re-

sistant mesh grille allows the microphone to be used during

the most challenging weather conditions. The supplied

windscreen further reduces “pop” and wind noise.

Features

•Neodymium magnet for increased output and high

signal-to-noise ratio

•Tailored frequency response with mid-range presence

rise for optimum speech clarity

•Omnidirectional polar pattern that eliminates need for

critical microphone positioning

•Internal isolation mount for low handling noise

•Water-resistant mesh grille repels water under challeng-

ing weather conditions

•Supplied windscreen for reduced pickup of pop and wind

noise

•Comfortable feel

•Handsome appearance; ideal for on-camera applications

•Legendary Shure ruggedness

SPECIFICATIONS

Type

Dynamic

Frequency Response

50 to 12,000 Hz (see Figure 1)

TYPICAL FREQUENCY RESPONSE

FIGURE 1

Polar Pattern

Omnidirectional

Impedance

Low (300 Ω actual)

Output Level (at 1,000 Hz)

Open Circuit Voltage: –51.5 dBV/Pa (2.7 mV)*

*1 Pascal = 94 dB SPL

Model VP64A and VP64AL

User Guide

27B3030 (Rev. 2)

2003, Shure Incorporated

Printed in U.S.A.

Produktspecifikationer

Varumärke:	Shure
Kategori:	mikrofon
Modell:	VP64AL
Höjd:	244 mm
Diameter:	38 mm
Gränssnitt:	XLR-3
Modell:	Intervjumikrofon
Mikrofonfrekvens:	50 - 12000 hz
Känslighet (1 kHz):	2.7
Produktens färg:	Svart
Hörlursutgång:	Nej
Antal produkter som medföljer:	1 styck
Mikrofonvikt:	179 g
Anslutningsteknologi:	Kabel
Mikrofon, riktning:	Rundtagande
Talspole typ:	Dynamisk
