X50V3L Series Quick Guide

【

English

】

53R-X50V33-2501

To place the machine on the desk and to carry it, do the following:

 PlacetheX50V3Lonaatsurfacesuchasatable(Picture1),andpullthestand

 upwardstoanangleof30°(Picture2).TocarryormoveyourX50V3Lfullyextend

 theangleto180°(Picture3).

VESA mounting it to the wall

Placing on the desk

Power LED

Webcam

Microphone

LCD Display (Single Touch / Non Touch)(Optional)

Front/Rear/Side View



Runthescreencalibration

program and correct 4 point

locations on screen with the

 panel.

Click

Start / All Programs

/ eGalax Touch

 /CongureUtility

Select

[Tools]tabandclick

[4 Points Calibration]

How to use the Touch Panel (Optional)



Whenthe4pointscalibrationcompleted,press tocontinue.[OK]

4 Point Calibration (Optional)

X50V3Lbringsdigitallifeforaneasytouchexperience.Experiencetheeaseof

 managingyourdigitallifewithafewtouchesortheuseofthestyluspen.The

 touchofyourngerreplacesthemouseandisallyouneedtointeractwiththe

 X50V3L.



Touchandholdthecenterofthetarget.

 Repeatonfourcornersandthescreenwilladjustautomatically.

Cleaning the screen

Followtheseguidelinesforcleaningtheoutsideandhandlingthescreenofthecomputer:

 Turnoffthesystemanddisconnectallcables.

Use a damp, or cleaning cloth, soft, lint-free cloth with gentle water only and gently

 wipethescreensurface.

 Donotsprayliquiddirectlyonthescreen.

・Touch=left-clickonthemouse

・Touchandhold=right-clickonthemouse

Followthesteps(1~3)belowtoconnecttheACadaptertothe jack.DCIN

Press the Power Buttontoturnonthesystem.

Poweringonthesystem

Stand / Handle

Stylus pen

Power Button

Power Input

DCIN

USB 2.0 Ports

SD card reader

Microphone Jack

LAN Port

Note:X50V3LcanbemountedtoawallusingaVESAcompatible

 100x100mmwall/armbracket.

IfyouaremountingyourX50V3Ltothewall,removethecoveronthebackof

 X50V3Lrst.

 Unscrew4screwsofthestandmountandremovethestand.

 TheVESAstandardletsusersmountitontowallseasily.

 Pleaserefertotheuserguideofthewall/armmountkityouboughttoinstallit.

Stereo speakers

Kensington® Lock Port

WiFi LED

COM Ports (Optional)

VGA Port

Note: Theproduct’scolorandspecicationwilldependupontheactuallyshippingproduct.

180

3.2.1.

Printer Port (Optional)

Hard disk drive LED

SafetyInformation

 ReadthefollowingprecautionsbeforesettingupaShuttleX50V3L.

CAUTION

Donotwalkonthepowercordorallowanythingtorestonit.

 Thewarrantydoesnotapplytotheproductsthathavebeendisassembledbyusers.

CAUTION

Dangerofexplosionifbatteryisincorrectlyreplaced.Replaceonlywiththesameor

 equivalenttyperecommendedbythemanufacturer.

 Disposeofusedbatteriesaccordingtothemanufacturer’sinstructions.

Touch

Hold OK

HDMI Port

USB 2.0 Ports

Stand / Handle

Headphone / Line-out Jack

A.BeginInstallation

1. RemovethecoveronthebackofX50V3L󰘰rst,unscrew

 fourscrewsofthestandmountandremovethestand.

Forsafetyreasons,pleaseensurethatthepower

cordisdisconnectedbeforeopeningthecase.

1. LocatetheSODIMMslotonthemainboard.

3. Gentlyinsertthe



 moduleintotheslot



 ina45-degreeangle.

SODIMMslot

5. Repeattheabovestepstoinstalladditionalmemorymodules,

 ifrequired.

Latch

B.HDDInstallation

2. Unscrewthreescrewsofthebracketandremoveit.

3. MountHDDintothebracketwithfourscrews.

4. Asshown,installtheHDD&bracketinthechassisand



 pushittowardsthedirectionasindicatedbytheredarrow



 toconnecttheHDDconnector.

5. TightentheHDD&bracketwiththreescrews.

1. Replacethebackcover,standandrefasteneightscrews.

D.Complete

2. Unscrewfourscrewsofthebackcoverandremoveit.

1. UnscrewfourscrewsoftheVESABaseandremoveit󰘰rst.

6.ReplacetheVESABaseandrefastenfourscrews.

2. Replacethecover,complete.

Cover

Screw

VESABase

C.MemoryModuleInstallation

2. Alignthenotchofthe

 memorymodulewith



 theoneofthememory



 slot.

45-degree

angle

4. Carefullypushdownthememorymoduleuntilitsnapsinto

 thelockingmechanism.

HDD

Connector

BackCover

Screw

VESABase

Stand/Handle

Ifyouinstallonlyonememorymoduleinyour

system,installitintheslotlabeled"DIMM2".

DIMM1DIMM2

Produktspecifikationer

Varumärke:	Shuttle
Kategori:	Kassaapparat
Modell:	POS X503
Bredd:	391.3 mm
Djup:	42 mm
Höjd:	327 mm
Strömförsörjning:	40 W
Skärm diagonal:	15.6 "
Upplösning:	1366 x 768 pixlar
Pekskärm:	Ja
Processorfrekvens:	1.86 GHz
Processorfamilj:	Intel Atom®
Wi-Fi:	Ja
Wi-Fi-standarder:	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ljudsystem:	IDT92HD81
Antal HDMI-portar:	1
Inbyggda högtalare:	Ja
Certifiering:	EMI: CE, FCC, BSMI, C-Tick, CCC, CB, BSMI, ETL, RoHS, Eup Lot6
Internminne:	2 GB
Bildförhållande:	16:9
Processor:	D2550
Processorns cache:	1 MB
Maximalt internminne:	4 GB
Total lagringskapacitet:	60 GB
Minnesplatser:	2 x SO-DIMM
Pekskärmsteknik:	Resistiv
Typ av minneskort:	SD, SDHC, SDXC
Produktens färg:	Svart
Monteringsbar på väggen:	Ja
Inbyggd kortläsare:	Ja
Installerat operativsystem:	Nej
Tillverkare av grafikadapter:	Intel
Datahastighet för Ethernet-LAN:	10,100,1000 Mbit/s
Antal LAN (RJ-45) anslutningar:	1
Temperatur vid drift:	0 - 35 ° C
Intervall för relativ operativ luftfuktighet:	10 - 90 %
Seriella portar:	2
Hållbarhetscertifiering:	ENERGY STAR
Typ av internminne:	DDR3
AC-inspänning:	100-240 V
Nätverksansluten (Ethernet):	Ja
Likströmsingång:	Ja
Linje ut:	Ja
Växelström Frekvens:	50 - 60 hz
Antal USB 2.0 anslutningar:	4
Moderkortets chipset:	Intel® NM10 Express
Video adapter:	GMA 3650
Produktvikt (oz):	Ja
Typ av kabellåsanslutning:	Kensington
Kvalitet på VGA (D-Sub) porten:	1
Gränsssnitt för panelmontering:	100 x 100 mm
Minne klockhastighet:	1066 MHz
Lagringsmedia:	SSD
Solid-state drive kapacitet:	60 GB
Uttag för mikrofon/linje in:	Ja
Antal talare:	2
Parallellport:	1
