Introduction
The Ultra Compact Wireless IR Remote Control Extender Kit – 200M extends IR remote control
signals wirelessly up to 200m (656ft). It allows you to move freely throughout your house and still
be in control of your A/V or IR enabled equipment.
Application
Supports IR signal frequency range from 20 to 60 KHz, compatible with most of IR-equipped devices
such as:
• DVD players
• Cable boxes
• Satellite receivers
• Audio/Hi-Fi stereo systems
• Other IR remote controlled devices
Package Contents
• Ultra Compact Wireless IR Remote Control Extender (TX & RX units)
• Power Adapters (x2)
• Dual IR Emitter Extension Cable
• IR Receiver Extension Cable
• User Reference Guide
Specifications
Transmission Frequency 915MHz
Modulation Type FSK (Frequency Shifted Keying)
Operating Range Up to 200m (656ft)
IR Frequency 20 ~ 60 KHz
IR Sensing Range Up to 5m
Power Adapter Input: AC 100-240V ~ 50/60Hz, Output: DC 5V/0.5A
Operating Temperature 32 to 104 degrees F
Storage Temperature 14 to 122 degrees F
Setup Instructions
1. Place the receiver unit, with red rubber ring, near the device you want to control remotely. Refer
to section for more details.Application Diagram
2. Connect the receiver’s (5VDC) to one of the included power adapters, and plug thepower jack
power adapter into an available power outlet.
3. Insert the included dual IR Emitter Extension Cable into the receiver’s Infrared 3.5mm socket.
Face the eye towards your source device's IR window.
4. Place the transmitter unit, with gray rubber ring, in the remote location where you want to use
the source device’s remote control. Make sure there is an available power outlet close by.
5. Connect the transmitter to the power outlet using the included power adapter.
6. Insert the included IR Receiver Extension Cable into the transmitter’s Infrared 3.5mm socket.*
7. The Wireless IR Remote Control Extender is ready for use.
* Note:
The image below shows the built-in IR receiver sensor zone. The source device’s IR remote control
can be pointed to this IR sensor to control it. Do not connect the IR Receiver Extension Cable if you
plan to use the built-in IR receiver sensor.
Application Diagram
The Wireless IR Remote Control Extender Kit enables you to control your IR-equipped source device
up to 200m remotely.
Safety Notice
• Always keep the unit dry. If it gets wet, wipe immediately to make it dry
• To prevent shock hazard, DO NOT expose the unit to liquids or water
• DO NOT place the unit on heated surfaces or next to other heat sources
• DO NOT attempt to replace any parts or open the case of the unit, opening the case can cause
personal injury due to electrical hazard and will void the manufacturer warranty
• Handle the unit with care. Dropping or undue force may cause irreparable damage
• DO NOT use corrosive cleaning substances or strong detergents on the unit
• Keep out of the reach of children
* Working angle +/-15 degrees
