Sida 1/2
FDX-AVPRO
Quick
Quick
Quick
QuickQuick Star
Star
Star
Star Start Guide
t Guide
t Guide
t Guidet Guide
800.AVI.2131
Tel: (818) 503-6200 Fax: (818) 503-6208
|
|
|
||
11651 Vanowen St. North Hollywood, CA 91605
SmartAVI.com
Designed and Manufactured in the USA
PART NO. QTY DESCRIPTION
FDX-AVPRO- 1 TX
DVI-D Fiber Optic Extender
Transmitter
FDX-AVPRO- 1 RX
DVI-D Fiber Optic Extender
Receiver
FDX-AVPRO-
TRANSCEIVER- TX
2
Fiber Optic Transceiver
Transmitter (Blue handle)
FDX-AVPRO-
TRANSCEIVER- RX
2
Fiber Optic Transceiver
Receiver (Yellow handle)
PS12VDC1A 2 Power Adapter
1 Quick Start Guide
WHAT’S IN THE BOX
NOTICE
The information contained in this document is
subject to change without notice. SmartAVI makes
no warranty of any kind with regard to this material,
including but not limited to, implied warranties of
merchantability and fitness for particular purpose.
SmartAVI will not be liable for errors contained
herein or for incidental or consequential damages
in connection with the furnishing, performance or
use of this material.
No part of this document may be photocopied,
reproduced, or translated into another language
without prior written consent from SmartAVI
Technologies, Inc.
20161130
Extends HD audio-video
signals up to 10km via a
single fiber optic cable
HD DVI-D Fiber Optic Extender
TECHNICAL SPECIFICATIONS
VIDEO
Format
DVI-D Single Link, Stereo Audio
(3.5 mm)
Maximum Pixel Clock 165 MHz
Impedance 100Ω
Max Data Rate 6.75 Gbps
Resolution
Up to 1080p (1920 x1080 @
60Hz)
Fiber Interface LC Connector
Fiber Type Single-mode fiber
Wavelength Single-mode 1310nm
Transmission Distance 10km
AUDIO
Interface 3.5mm earphone seat
Signal Type Stereo
RS- 232
Signal Direction Unidirectional
Max Baud Rate 115200bps (Self-adaptive)
Data Bits 8
OTHER
Power Adapter 12VDC1A
Weight (TX+RX) 1.8 lbs.
Dimensions (Each) 1.125” H x 6” W x 4.75”D
Approvals UL, CE, ROHS Compliant
Operating Temp 32 to 131°F (-5 to 70 °C)
Operating Humidity 5 to 90% (no condensation)
