Contents

1 INTRODUCTION .........................................................................................3

2 SAFETY INFORMATION .............................................................................5

3 INSTALLATION MATERIAL .........................................................................8

3.1 Kit supplied with dishwasher .......................................................................9

4 DIMENSIONS OF DISHWASHER .............................................................10

5 INSTALLATION AND HOOK-UP ................................................................11

5.1 Leveling ......................................................................................................12

5.2 Connections ...............................................................................................13

5.2.1 Connecting to the water supply ..................................................................14

5.2.1.1 Connecting to the water tap .......................................................................15

5.2.1.2 Connecting the drain hose .........................................................................17

5.2.2 Electrical connections and warnings ..........................................................22

5.3 Commissioning ..........................................................................................23

5.3.1 Installation procedure .................................................................................23

5.4 Testing. .......................................................................................................27

ENCONTENTS

NO I T CUDOR T N I1

Thank you for choosing one of our products. To install this dish-

washer correctly and safely, please read this manual carefully. The

manual is divided into sections giving you a step-by-step guide to

installation of the appliance. The texts are easy to understand and

are complete with detailed illustrations. This user-friendly manual will

provide answers to all your questions about installation of the dish-

washer.

This manual comprises the following sections:

INTRODUCTION: general information about the manual.

WARNINGS: a list of warnings concerning safety during installation.

INSTALLATION INSTRUCTIONS: for the qualiﬁed technician who

must carry out the installation, hook-up and testing of the appli-

ance.

Nomenclature of ﬁgures and tables:

The progressive number of each ﬁgure is shown in the bottom right-

hand corner of the relative box. An example of a progressive number

is “Fig. 4-01”, where the ﬁrst number (4) indicates the section to

which the ﬁgure belongs, while the second number (01) indicates

the progressive number of the ﬁgure in section 4 (Fig. 4-01 is the

ﬁrst ﬁgure in section 4). The tables are numbered in the same way,

bearing in mind that “Tab.” is used instead of “Fig.” (e.g.: Tab. 4-01

is the ﬁrst table in section 4). If a table occupies more than one page,

a letter is added after the progressive number (e.g.: “Tab. 4-01a”,

Tab. 4-01b”).

CONTENTS
