Introduction

Thank you for purchasing Sonance Visual Performance

®

Series Medium rectangle speakers. When properly installed your

new speakers will give you years of entertainment pleasure.

Box Contents

Each Sonance Visual Performance Series Medium rectangle

speaker box contains (2) Visual Performance Series speakers,

(2) paint plugs (installed on the fronts of the speakers),

(2) paintable grilles and (1) mounting cut-out template.

Speaker Placement

Home Theater Speaker Placement

Left, Center & Right Speakers

• Place the left & right speakers on either side of the video

screen, 6 – 10 feet (1.8m – 3m) apart and 3 – 4 feet

(0.9m – 1.2m) from the floor.

• If possible, locate the center speaker at the same height as the

left & right channel speakers.

• If you must place the center speaker above or below a video

screen, place it no more than 2 feet (0.6m) above or below the

center of the left and right speakers. This will maintain consis-

tent tonality between all three front channel speakers.

• The main listening position should be 8 – 12 feet

(2.4m – 3.7m) away from the speakers.

Use

Figure 1

as a guide.

Surround Speakers (5.1-Channel System)

Locate the surround channel speakers on the side walls 2 – 6 feet

(0.6m – 1.8m) behind the listening position, 5 – 7 feet

(1.5m – 2.1m) from the floor. Use

Figure 2

as a guide.

Surround Speakers (7.1-Channel System)

• LEFT& RIGHTSURROUNDSPEAKERS:Place the left and right

surround speakers directly to the sides of the listening position,

at least 5 feet from the floor.

• S

URROUNDBACKSPEAKERS:Place the surround back speakers in

the rear wall, 3 – 6 feet (0.9m – 1.8m) apart and 5 – 7 feet

(1.5m – 2.1m) from the floor.

Use

Figure 3

as a guide.

INSTRUCTION MANUAL

VISUAL PERFORMANCE

®

SERIES

MEDIUMRECTANGLE SPEAKERS

SAFETYWARNING:

THESESPEAKERSHAVEFASTMOUNT

®

TABSTHATPREVENTTHE

SPEAKERFROMFALLINGOUTOFTHEMOUNTINGHOLEDURINGTHE

INSTALLATIONPROCESS

.

THEEDGESOFTHEFASTMOUNTTABSAREVERYSHARP.

U

SECAUTIONWHENHANDLINGTHESPEAKER.

18"

(0.5m)

From Side

Wall

18"

(0.5m)

From Side

Wall

2'

(0.6m)

max.

6' – 10'

(1.8m – 3m)

Apart

FIGURE1: LEFT, CENTER& RIGHTCHANNEL

HOMETHEATERSPEAKERPLACEMENT

5' – 7'

(1.5m – 2.1m)

2' – 6'

(0.6m – 1.8m)

FIGURE2: 5.1-CHANNELHOMETHEATERSURROUNDSPEAKER

PLACEMENT

Right Surround

Speaker

Left Surround

Speaker

Left

Front

Speaker

Right

Front

Speaker

Video

Screen

Center

Speaker

Left

Surround Back

Speaker

Right

Surround Back

Speaker

FIGURE3: 7.1-CHANNELHOMETHEATERSPEAKERPLACEMENT
