Sida 1/6

eGPU Breakaway Puck Description

2 – USB Type A Ports

Connect USB devices, such as a mouse or keyboard, to these ports.

3 – DisplayPort 1.4 Port

4 – HDMI 2.0b Port

5 – Thunderbolt 3 Port (Computer)

Connect the included Thunderbolt cable, or a comparable

Thunderbolt 3 (40Gbps) cable, between this port and your

computer’s Thunderbolt 3 port.

6 – Thunderbolt 3 Port (Display)

Connect a Thunderbolt 3 display to this port. You may connect a

USB-C to DisplayPort or HDMI adapter instead.

7 – DC 20V Socket

Connect the included DC power adapter between this socket and

the included power cord.

WARNING

The eGPU Breakaway Puck may become hot during

operation. Follow these precautions:

1. The Breakaway Puck’s metal surfaces can get hot when you are

extensively using the GPU, and you may burn your ﬁngers if you

touch a surface for more than a few seconds.

2. Before handling, switch off the Puck and wait 10 minutes.

FCC Compliance

eGPU Breakaway Puck complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions: This device

may not cause harmful interference, AND this device must accept

any interference received, including interference that may cause

undesired operation.

Contacting Customer Service

Before contacting Customer Service, please check the Sonnet Web

site (www.sonnettech.com) for the latest updates and ﬁles. Email

requests generally receive the fastest responses, and are usually

processed within a 24-hour period during normal business hours,

excluding holidays. When you contact Customer Service, please have

the following information available:

Product name • OS version • A System Report (macOS) or a

Microsoft System Information MSINFO32 (Windows) report

(Windows), along with a description of the issue(s) you are

encountering with your device

If further assistance is needed, contact Sonnet Customer Service at:

E-mail: support@sonnettech.com

Tel: 1-949-472-2772

(Monday–Friday, 9 a.m.–5 p.m. Paciﬁc Time, excluding holidays)

You Should Have In Your Product Package:

One eGPU Breakaway Puck • One DC power adapter • One power

cable • One Thunderbolt

™

3 (40Gbps) cable • Quick Start Guide

Mac

Compatibility

• Mac with Thunderbolt 3 ports

• macOS

10.15.6+

WINDOWS

USERS: Download the Windows eGPU Use Guide at

https://www.sonnettech.com/support/downloads/manuals/windows_

egpu_info.pdf

Technologies, Inc. Thunderbolt 3 and the Thunderbolt logo are trademarks of Intel Corporation in the U.S. and/or other countries.

Other product names are trademarks of their respective owners. Product specifications subject to change without notice.

QS-GPU-RX5XXX-TB3-E-A-080420

Mac Setup Overview

Drivers that support the eGPU Breakaway Puck are installed as part of

macOS; the Puck is ready to use when connected to your computer.

1. If you are connecting displays to the Puck, do so now.

2. Connect the power cord between the power adapter and a wall

outlet or power strip, and then connect the power adapter’s cable

to the Puck’s power socket. Note that the Puck’s power LED (1) will

not light until the computer is turned on.

3. Connect the included Thunderbolt cable between the

Thunderbolt 3 (Computer) port on the Puck and a Thunderbolt 3

port on your computer.

4. Turn on your computer. The

eGPU icon

will appear

in the menu bar, and the

Puck’s power LED (1) will

light to indicate the Puck is

recognized and ready for use.

Support Notes: For a complete eGPU Breakaway Puck User’s

Guide (in English), please visit: https://www.sonnettech.com/

support/kb/kb.php, click the Thunderbolt link, and then click eGPU

Breakaway Puck.

For more detailed information on eGPU use under macOS, download

Sonnet’s macOS External Graphics Guide: https://www.sonnettech.

com/support/downloads/manuals/macos_egpu_info.pdf

Support Notes: If you’re using a 2016 or 2017 13-inch

MacBook Pro, always connect the Puck to one of the left-hand

Thunderbolt 3 ports for maximum data throughput.

Quick Start Guide

eGPU Breakaway

™

Puck

Produktspecifikationer

Varumärke:	Sonnet
Kategori:	Annat datortillbehör
Modell:	GPU-RX57-TB3-S
Vikt:	1470 g
Bredd:	152 mm
Djup:	130 mm
Höjd:	51 mm
Strömförsörjning:	230 W
Antal HDMI-portar:	1
HDCP:	Ja
HDMI-version:	2.0b
Värdgränssnitt:	Thunderbolt 3
DisplayPort-version:	1.4
HDCP-version:	2.2
Antal Thunderbolt-portar:	2
Produktens färg:	Svart
bruksanvisning:	Ja
HD-typ:	4K Ultra HD
Antal displayportar:	1
Vikt inkl. förpackning:	2180 g
Windows-operativsystem som stöds:	Windows 10
Temperatur vid drift:	0 - 35 ° C
Hållbarhetscertifiering:	RoHS
AC-inspänning:	100 - 240 V
Kabel inkluderad:	AC, Thunderbolt
Anslutningsteknologi:	Kabel
Nätverksansluten (Ethernet):	Nej
Strömkälla av typen:	AC, DC
Växelström Frekvens:	50 - 60 hz
AC-adapter inkluderad:	Ja
Antal USB 3.2 Gen 2 (3.1 Gen 2) typ A-portar:	2
Manual:	Ja
Uppfyller hållbarhetskrav:	Ja
Uttag för mikrofon/linje in:	Nej
Laddning funktion:	Ja
