Quick Start Guide

Mac® Compatibility

• Mac with Thunderbolt 3 ports

• macOS

10.13.6+

• macOS Catalina compatible

Windows® Compatibility

• PC with Thunderbolt 3 ports

• 64-bit editions of Windows

10, Version 1809 or later

Important Note: Windows computers require the latest BIOS and

Thunderbolt drivers to support this product. Check with your

computer manufacturer for update information.

Linux® Compatibility

• PC with Thunderbolt 3 ports

• Linux Kernel 5.0 or later

Thunderbolt 3 Connector—Plug this connector into one of your

computer’s Thunderbolt 3 ports (often indicated by a

logo), or at the

end of a Thunderbolt device chain. Ports marked with the USB icon

(

) are NOT compatible.

Driver Information

For Mac users, the drivers required to support this product are

installed as part of macOS 10.13.6 and later; the Sonnet adapter is

ready for use when you power on your computer.

For Windows users, please go to www.sonnettech.com/support/kb/

kb.php. Navigate to and click the Solo10G Thunderbolt 3 Edition

link, and then click the Driver link. Locate, download, and install

the Windows drivers.

For Linux users, the drivers required to support this product are

installed as part of Linux Kernel 5.0 and later, though more current

drivers may be available: Go to www.sonnettech.com/support/kb/

kb.php, navigate to and click the Solo10G Thunderbolt 3 Edition

link, and then click the Driver link. If the listed Linux driver version

is later than the one installed in your system, download and install

the drivers.

Solo

™

Thunderbolt

™

Edition

10GBASE-T

NBASE-T® to Thunderbolt 3 Adapter

Solo10G Thunderbolt 3 Edition Description

1 – RJ45 (10GBASE-T/NBASE-T) Port

Connect a CAT 6A, CAT 6 or CAT 5e* cable between this port

and the switch’s or device’s RJ45 port.

2 – Link/Activity Indicator

This LED ﬂashes green to indicate a link is established between

the adapter and the switch, and ﬂashes yellow when the link is

training.

3 – Link Speed Indicator

When a link is established between the adapter and the switch,

this LED lights to indicate the link speed to the switch: green =

10Gb; yellow = 5Gb, 2.5Gb, 1Gb, or 100Mb.

* 10 Gb/s speed supported on CAT 6A and CAT 6 cabling at 100 and

55 meters, respectively. Lower speeds supported on CAT 5e and

better cabling at up to 100 meters. 5 Gb/s and 2.5 Gb/s link speed

support requires an NBASE-T (multi-Gigabit) compatible switch.

trademarks of Sonnet Technologies, Inc. Mac, the Mac logo, and macOS are trademarks of Apple

Inc., registered in the United States and other countries. Thunderbolt and the Thunderbolt logo

are trademarks of Intel Corporation in the U.S. and/or other countries. Other product names are

trademarks of their respective owners. Product specifications subject to change without notice.

QS-SOLO10G-TB3-E-F-101620

Support Note: This document was up to date at the time of

printing. However, changes to the

hardware or software may have occurred since then. Please check the

Sonnet website for the latest documentation.

1. Go to https://www.sonnettech.com/support/kb/kb.php

2. Navigate to and click the Solo10G Thunderbolt 3 Edition link.

3. Click the Manual link.

4. Click the Solo10G Thunderbolt 3 Edition Quick Start Guide [English]

link and then check the Document Version information. If the

version listed is later than this document (revision F), click the

Download Now button for the latest version.

Produktspecifikationer

Varumärke:	Sonnet
Kategori:	Nätverkskort/adapter
Modell:	SOLO10G
Vikt:	240 g
Bredd:	79.5 mm
Djup:	114 mm
Höjd:	27.2 mm
Gränssnitt:	Ethernet
Maximal räckvidd:	100 m
Värdgränssnitt:	Thunderbolt 3
Maximal dataöverföringshastighet:	10000 Mbit/s
Komponent för:	PC
Kabellängd:	0.5 m
Produktens färg:	Svart
bruksanvisning:	Ja
Antal LAN (RJ-45) anslutningar:	1
Temperatur vid drift:	0 - 35 ° C
Hållbarhetscertifiering:	RoHS
Anslutningsteknologi:	Kabel
Wake-on-LAN förberedd:	Ja
Kommunikationsstandarder:	IEEE 802.3az
Intern:	Nej
Kretsar:	Aquantia AQC-107S
Jumbo Frames stöd:	Ja
Flödeskontroll:	Ja
