Sida 1/22

User’s Guide

for xMac Studio

Support Note: This document was up to date at the

time of printing. However, changes to the

hardware or software may have occurred since then. Please

check the Sonnet website for the latest documentation.

1. Go to https://www.sonnettech.com/support/kb/kb.php

2. Navigate to and click the xMac Studio link.

3. Click the Manual link.

4. Click the xMac Studio User’s Guide [English] link and then

check the Document Version information. If the version

listed is later than this document (revisionE), click the

Download Now button for the latest version.

1 Introduction and System Requirements 1

Introduction

Mac Compatibility

System Requirements

2 xMac Studio Description 2

Front Panel

Back Panel — xMac Studio / Echo III

Back Panel — xMac Studio / Echo I

Echo III Module Interior

Echo I Module Interior

Additional Package Contents

3 Computer Installation and Module Removal Steps 7

4 Echo III Module PCIe Card Installation Steps 9

5 Echo I Module PCIe Card Installation Steps 11

6 Echo Module Installation Steps 12

7 Accessory Installation Steps (Optional) 13

8 Final Assembly and Enclosure Installation Steps 15

9 Complete Setup and Configuration 17

10 Tips, General Information, and Known Issues 18

Tips, General Information

Known Issues

11 Precautions, FCC Compliance, and Support Information 19

Safety Precautions

FCC Compliance

Contacting Customer Service

Contents

Section 1 – Introduction and System Requirements

Introduction

Congratulations on your purchase! xMac Studio is a

rackmount enclosure for Mac Studio™ computers and

Sonnet Echo Thunderbolt expansion modules for PCIe

cards. Through a module’s PCIe slot(s), you may connect

one or three non-GPU adapter cards to your Mac Studio to

expand its capabilities and add connectivity beyond what’s

offered through its native ports.

Mac® Compatibility

• Mac Studio computers with PCIe cards that have M

series processor-compatible drivers

• macOS

12.3+

System Requirements

While Echo modules require no drivers beyond those pre-

installed in your computer’s OS, many expansion cards

you install do; Thunderbolt-compatible drivers to enable

them to work properly through the Thunderbolt interface

are required. More information on which cards are

compatible with Echo I and Echo III Modules is available

at: https://sonnettech.com/support/

Produktspecifikationer

Varumärke:	Sonnet
Kategori:	Extern hårddisk
Modell:	xMac Studio
Inbyggd display:	Nej
Lagringsenheter installerade:	Nej
Total installerad lagringskapacitet:	- GB
Kompatibla produkter:	Mac Studio
Enhetsklass:	Små och Medelstora Företag
Antal lagringsenheter som stöds:	1
Typer av lagringsenheter som stöds:	SSD
Produktens färg:	Svart
Typ av installerad lagringsenhet:	Nej
Antal USB 2.0 anslutningar:	4
Högsta lagringskapacitet:	- TB
Lagringsenhetens kapacitet:	- GB
Chassityp:	Rack (3U)
Nätaggregatets effekt:	- W
Kuggskenor:	Ja
