Sony XR-85Z9K Bruksanvisning

Sony Tv XR-85Z9K

Läs gratis den bruksanvisning för Sony XR-85Z9K (2 sidor) i kategorin Tv. Guiden har ansetts hjälpsam av 23 personer och har ett genomsnittsbetyg på 4.5 stjärnor baserat på 12 recensioner. Har du en fråga om Sony XR-85Z9K eller vill du ställa frågor till andra användare av produkten? Ställ en fråga

Ladda ner PDF

Sida 1/2

About Manuals

This TV comes with the following manuals. Please retain the manuals for future reference.

Note

• Before operating the TV, please read the “Safety Information”.

• Read the supplied safety documentation for additional safety

information.

• Instructions about “Installing the TV to the Wall” are included within this

TV’s instruction manual.

• Images and illustrations used in the Setup Guide and this manual are for

reference only and may differ from the actual product.

• Setting menus are subject to change without notice due to software

updates.

For latest information, visit Sony support website.

Location of the identification label

Labels for the TV Model No. and Power Supply rating are located on the

rear of the TV. They can be found by removing the terminal cover.

Installation/Set-up

Install and use the TV set in accordance with the instructions below in

order to avoid any risk of fire, electric shock or damage and/or injuries.

Installation

• The TV set should be installed near an easily accessible AC power outlet

(mains socket).

• Place the TV set on a stable, level surface to prevent it from falling over

and causing personal injury or property damage.

• Install the TV where it cannot be pulled, pushed, or knocked over.

• Install the TV so that the TV’s Table-Top Stand does not protrude out

from the TV stand (not supplied). If the Table-Top Stand protrudes out

from the TV stand, it may cause TV set to topple over, fall down, and

cause personal injury or damage to the TV.

Transporting

• Before transporting the TV set, disconnect all cables.

• Before transporting the TV set, remove the terminal covers.

• Three or more persons are needed to transport a large TV set.

• When transporting the TV set by hand, hold it as shown below. Do not

put stress on the panel and the frame around the screen.

• When transporting the TV set, do not subject it to jolts or excessive

vibration.

• When transporting the TV set for repairs or when moving, pack it using

the original carton and packing material.

Setup Guide

• TV installation and setup.

Reference Guide (this manual) / Safety Documentation

• Safety information, remote control, troubleshooting, wall-mount installation,

specification, etc.

Help Guide (On screen Manual)

• Settings, functions, Internet connection,

troubleshooting, etc.

• To open it, press (Input select) on the remote

control and select [Help]. If [Help] does not exist,

select [Edit] and add [Help].

• You can refer to the Help Guide with your

smartphone.

https://rd1.sony.net/help/tv/

jga1/h_ga/

IMPORTANT – Read the End User Software Licence Agreement

before using your Sony product. Using your product indicates your

acceptance of the End User Software Licence Agreement. The software

licence agreement between you and Sony is available online at Sony

website (https://www.sony.net/tv-software-licenses/) or on your

product screen. Press (Quick Settings) on the remote control and

select [Settings]  [System]  [About]  [Legal information] 

[Notices and licences].

Safety Information

Topple prevention

(Models with supplied support belt kit)

Refer to the Setup Guide on top of the cushion.

The supplied wood screw is only for affixing to a solid object made of

wood.

(Except models with supplied support belt kit)

Using TV as Centre Speaker

Note

• Before connecting cables, disconnect the AC power cord

(mains lead) of both TV and AV receiver.

Using TV as Part of Audio System

Note

• Before connecting cables, disconnect the AC power cord

(mains lead) of both TV and AV receiver.

• Refer to the instruction manual of the Audio system with

S-CENTER OUT terminal for detail.

Remote Control and TV

The remote control shape, layout, availability and

function of remote control buttons may vary

depending on your region/country/TV model/TV

settings*

 (Power)

TV:

Display TV channel list or switch to input.

(Quick settings): Display Quick Settings.

(Input select): Display and select the input

source, etc.

123 (Control menu): Display the Control menu.

  /  /  /  / : On screen menu navigation

and selection.

(Back)

(Home)

(Google Assistant) / (Microphone):

Use

Google Assistant*

or voice search*

 + / – (Volume)

(Mute)*

CH + / – (Channel)

(Guide):

Display the digital programme guide

of TV or TV box*

 App buttons*

 (Power): (It can be found by removing the side

cover)



BUILT-IN MIC SWITCH: Turn on/off the built-in

MIC. (It can be found by removing the side cover)



Built-in MIC*

: To enable the built-in MIC,

press the Google Assistant/microphone button on

the remote control and follow the on-screen

instructions.

 Remote Control sensor / Ambient light

sensor / LED

*1 For other remote control models, refer to the online Help

Guide for details.

*2 The remote control backlight will illuminate when the light

sensor detects the ambient light is low. Automatic

illumination of the backlight can be turned off.

*3 The buzzer will emit a sound when you use the remote

finder function. Refer to the online Help Guide for details.

*4 Only for limited region/country/model/language.

*5 Google Assistant or voice search requires an Internet

connection.

*6 Accessibility shortcut is available by pressing and holding

(Mute).

*7 [TV box setup] setting is required.

*8 Installation of the NETFLIX app may be required depending

on your region/country.

*9 Power consumption will increase when the built-in MIC is

enabled as it is always listening.

Installing the TV to the Wall

Using the optional Wall-Mount Bracket (SU-WL450)*

(not supplied)

To Customers:

For product protection and safety reasons, Sony

strongly recommends that installation of your TV be

performed by Sony dealers or licensed contractors. Do

not attempt to install it yourself.

To Sony Dealers and Contractors:

Provide full attention to safety during the installation,

periodic maintenance and examination of this

product.

Wall-Mount Bracket Installation Information

For instructions on Wall-Mount Bracket installation,

see the Installation Information (Wall-Mount Bracket)

on the product page for your TV model.

https://www.sony-asia.com/support

• Follow the instruction guide provided with the Wall-

Mount Bracket for your model. Sufficient expertise is

required in installing this TV, especially to determine

the strength of the wall for withstanding the TV’s

weight.

• Sony is not liable for any damage or injury caused by

mishandling or improper installation.

• Only qualified service personnel should carry out

wall-mount installations.

• For safety reasons, it is strongly recommended that

you use Sony accessories, including:

—Wall-Mount Bracket SU-WL450

• Be sure to use the screws supplied with the Wall-

Mount Bracket when attaching the Wall-Mount

Bracket to the TV set. The supplied screws are

designed as indicated by illustration when measured

from the attaching surface of the Wall-Mount

Bracket.

The diameter and length of the screws differ

depending on the Wall-Mount Bracket model.

Use of screws other than those supplied may result

in internal damage to the TV set or cause it to fall,

etc.

• Be sure to store the unused screws and Table-Top

Stand in a safe place until you are ready to attach the

Table-Top Stand. Keep the screws away from small

children.

* Only for limited region/country/model.

10 mm – 12 mm

M6 screw

(not

supplied)

Screw

(not supplied)

Cord

(not supplied)

1.5 N·m

{15 kgf·cm}

AV Receiver

Speaker cable

S-CENTER

OUT

TV centre

speaker

mode

cable

HDMI

(eARC/ARC)

connection

Light sensor*

MIC

Buzzer*

For more information, refer to the Help

Guide.

Press (Input select) on the remote

control and select [Help]. If [Help] does

not exist, select [Edit] and add [Help].







Screw (M6)

Wall-Mount Bracket

10 mm - 12 mm

TV’s rear cover

Television

5-040-296-11(1)

XR-85Z9K

Reference Guide

Produktspecifikationer

Varumärke:	Sony
Kategori:	Tv
Modell:	XR-85Z9K
Höjd:	1223 mm
Förpackningens bredd:	2004 mm
Automatisk avstängning:	Ja
Skärm diagonal:	85 "
Upplösning:	7680 x 4320 pixlar
Wi-Fi:	Ja
Wi-Fi-standarder:	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth-version:	4.2
Bluetooth-profiler:	A2DP, AVRCP, HID, HOGP, SPP
Ljudformat som stöds:	3GPP, AAC, FLAC, MP3, MP4, OGG, WAV
Videoformat som stöds:	3GPP, ASF, AVC, AVCHD, AVI, HEVC, MJPG, MKV, MOV, MP4, MPEG1, MPEG2, MPEG2-PS, MPEG2-TS, MPEG4, VP8, VP9, WEBM, XVID
Appdistributionsplattform:	Google Play
Videolägen som stöds:	480p, 576p, 720p, 1080i, 1080p, 2160p, 3840p, 4320p
Färgnamn:	Titanium Silver
Skärmform:	Platt
Ljusstyrka:	- cd/m²
LED-bakgrundsbelysning:	Ja
Antal HDMI-portar:	4
HDCP:	Ja
Wi-Fi Direct:	Ja
HDR-stöd:	Ja
Bluetooth Low Energy (BLE):	Ja
HDMI-version:	2.3
Grafikupplösningar som stöds:	3840 x 2160,4096 x 2160,7680 x 4320
Common Interface Plus (CI+):	Ja
Typ av tuner:	Analog och digital
Internet-TV:	Ja
Stöd för Apple AirPlay 2:	Ja
Ljudlägen:	Cinema, Dialog, Dolby Audio, Music, Sports, Standard
Adaptiv ljudkontroll (ASC):	Ja
Energieffektivitetsklass (SDR):	G
Energieffektivitetsklass (HDR):	G
webbläsare:	Ja
Rullbar skärm:	Nej
Vikt (med stativ):	60100 g
Bildbehandlingsteknik:	Sony Cognitive Processor XR, Sony Dynamic Contrast Enhancer, Sony Live Colour, Sony XR HDR Remaster, Sony XR Smoothing, Sony XR Super Resolution, Sony XR Triluminos Pro
Inbyggd subwoofer:	Ja
På/av timer:	Ja
Consumer Electronics Control (CEC):	BRAVIA Sync
Automatisk kanalsökning:	Ja
Spelläge:	Ja
Energisparläge:	Ja
Videouppskalning:	Ja
HID-stöd:	Ja
Subwoofertyp:	Aktiv subwoofer
Detektering av ljusstyrka:	Ja
ConnectShare (USB):	Ja
ConnectShare (HDD):	Ja
Inbyggd Chromecast:	Ja
Fjärrkontroll ingår:	Ja
Fungerar med Google Assistant:	Ja
Spelfunktioner:	Auto Low Latency Mode (ALLM), Variable Refresh Rate (VRR)
Dialogförbättring:	Ja
TV-ljud till mobil enhet:	Ja
Smarta funktioner:	Cinema, Custom, Dolby Vision Bright, Dolby Vision Dark, Game, Graphics, IMAX Enhanced, Photo, Standard, Vivid
Färgdetektering:	Ja
Produktens färg:	Titan
HD-typ:	8K Ultra HD
Bredd (utan stativ):	1896 mm
Höjd (utan stativ):	1096 mm
Vikt (utan stativ):	58400 g
Bredd (med stativ):	1896 mm
Djup (med stativ):	460 mm
Höjd (med stativ):	1123 mm
Skärmtyp:	LCD
Analogt signalformatsystem:	NTSC M, PAL M
VESA-fäste:	Ja
Förpackningstyp:	Låda
Låddjup:	246 mm
Vikt inkl. förpackning:	73000 g
Eco-läge:	Ja
Uteffekt (RMS):	85 W
Skrivbordsstativ:	Ja
Djup (utan stativ):	74 mm
Digitalt signalformatsystem:	ATSC
Elektronisk programguide (EPG):	Ja
Energiförbrukning (SDR) per 1 000 timmar:	168 kWh
Energiförbrukning (HDR) per 1 000 timmar:	200 kWh
Installerat operativsystem:	Android TV
Antal LAN (RJ-45) anslutningar:	1
Strömförbrukning (vanlig):	168 W
Föräldrakontroll:	Ja
AC-inspänning:	220-240 V
Equalizer:	Ja
Kabel inkluderad:	AC
OSD-språk:	AFR, ALB, ARA, BEL, BOS, BUL, CHI (SIMPL), CHI (TR), CRO, CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HIN, HUN, IND, ITA, JPN, KAZ, KOR, LAT, LAV, LIT, MAC, NOR, PER, POL, POR, RUM, RUS, SCR, SER, SLV, SWA, SWE, THA, TUR, UKR, VIE, ZUL
Subwoofer RMS-effekt:	20 W
Ljuddämpning:	Ja
Nätverksansluten (Ethernet):	Ja
Firmware kan uppgraderas:	Ja
röstguide:	Ja
Växelström Frekvens:	50 hz
Diagonal skärmstorlek:	215 cm
Typ av LED-bakgrundsbelysning:	Full-Array
Smart-TV:	Ja
På / av-knapp:	Ja
Bildgalleri:	Ja
Subwoofer ingår:	Ja
Energieffektivitetsskalning:	A till G
Antal USB 2.0 anslutningar:	2
Strömförbrukning i vänteläge:	0.5 W
HDR-teknik (High Dynamic Range):	Dolby Vision, High Dynamic Range 10 (HDR10), Hybrid Log-Gamma (HLG)
Bluetooth:	Ja
Plug & Play-kompatibel:	Ja
Webbläsare stöds:	Vewd
Smartphone fjärrsupport:	Ja
Röststyrning:	Ja
Svarstid (medel):	- ms
Gränsssnitt för panelmontering:	400 x 400 mm
Antal S-Video-ingångar:	1
Ingående kompositvideo:	1
Digital optisk utgång för ljud:	1
PC-In (D-Sub):	Nej
Antal talare:	6
Standard uppdateringsfrekvens:	120 hz
Skärmgränssnitt (OSD):	Ja
Vilolägestimer:	Ja
Antal RF-ingångar:	1
Rörelse-interpoleringsteknik:	XR Motion Clarity
Vanligt gränssnitt (CI):	Ja
Bläddrar:	Ja
Inspelning via USB:	Ja
Inbyggd ljuddekoder:	DTS, Dolby Atmos, DTS Digital Surround
Ljudreturkanal (ARC):	Ja
Videoappar:	Google TV, Netflix
4K-uppskalningsfunktion:	Ja
Förstärkt returkanal för audio (eARC):	Ja
TV-band som stöds:	UHF, VHF
Stativ, bredd:	1895 mm
Introducerades år:	2022
Färg på stativet:	Titan
Typ av stativ:	Benstativ
Typ av metallring:	3 Bezel-less
Deskriptor för förhandsval av ljud:	Ja
Anpassningsbart ljud:	Ja
Skärmuppdateringsfrekvenser som stöds:	24 Hz, 25 Hz, 30 Hz, 50 Hz, 60 Hz, 100 Hz, 120 Hz
Anpassningsbar bild:	Ja
Fjärråtkomst:	Ja
Calman Ready:	Ja
Stöd för 360°-kamera:	Ja
