Sida 1/1
Do not spec or install speaker near support beam, ventilation duct or
other structure that may interfere with speaker function or dispersion.
Warning Warning
SoundTube speakers must be installed by a professional audio installer/contractor. For safety and for
optimum audio performance, installer must follow all directions issued by SoundTube Entertainment.
Wire Color
Black
Brown
Orange
Yellow
Blue
70V-Common
10W
5W
2.5W
1.3W
100V-Common
NC
10W
5W
2.5W
RF52
Tap Wire
Key
1. 2.
2. Connect speaker wires
to signal wires using
included wire nuts.
Select the desired wire for
the intended tap setting as
indicated on the chart
below.
4. Tighten each clamping
wing screws until they are
snug and the speaker ts
rmly against the ceiling.
DO NOT OVERTIGHTEN.
3. Place the speaker in the
opening. If installing in an
existing backcan, make sure
the clamping wings are
positioned such that their
operation will not be
obstructed by any material or
objects inside the back can.
Box contents
1 Speaker
1 Grille
2 Wire nuts
© 2017 SoundTube Entertainment, Inc. All rights reserved. PN INS-RF52-EZ Rev 06.25.19
1. Unpack speaker.
6. Done.5. Place the grill over the
center of the speaker. The
magnets will hold it in place.
Install Instructions For:
RF52-EZ speaker
RF52-EZ-WH
