1.0 Introduction

A key component of a physical security electronic access control

system, a mobile-ready reader combining BLE and proximity

technologies is based on RFID technology. In operation it is capable of

reading data stored on a proximity credential via radio frequency—or

reading data from mobile credential stored in a smartphone’s wallet

app via BLE technology—and without physical contact, and then

passing the data obtained to the physical access control system.

Access control systems typically manage and record the movement of

individuals through a protected area, such as a locked door.

2.0 Mounting Provisions

Each reader may be installed either indoors or outdoors. Mounting

options shown in the table below. Use supplied #6 mounting screws,

or equivalent security screws, for installation.

*Plastic or metal

3.0 Reader Wiring

Wiegand Magstripe

Conductor Function Conductor Function

Red DC (8-14 VDC) Red DC (8-14 VDC)

Black Ground Black Ground

Green Data 0 Green Clock

White Data 1 White Data

Brown Red LED

Orange Green LED

Yellow Card Present Yellow Card Present

Blue Beeper Blue Beeper

Violet ﬂeaPower Violet ﬂeaPower

Drain Shield Ground Drain Shield Ground

WIRING NOTES:

Single Line LED: This is the standard operating mode and does not make use of the

Orange conductor. The LED is Red when the reader is idle and ﬂashes when a card is

presented. The LED turns Green when the Brown Conductor is pulled low by the access

control panel.

Dual Line LED: This mode makes use of both the Brown and Orange conductors. The

Brown conductor controls the Red LED and the Orange conductor controls the Green

LED. LED states are determined by the access control system option and capability.

Unused conductors should be trimmed, isolated and taped back to prevent unintended

current ﬂows. Apply positive voltage only to the Red DC Conductor.

4.0 Cable Requirements

24 AWG minimum, multi-conductor stranded with an overall foil shield,

for example Belden 9535 or similar, supporting the ﬁve conductors

comprising the physical layer of the Wiegand interface (power, ground,

data 0, data 1, and/or beeper and LED). Alternatively, Belden 9539 or

similar, for all reader functions. Contact your access control system

manufacturer for their speciﬁc requirements. Per the SIA’s Wiegand

speciﬁcation, maximum cable length is 500 feet (152 m).

5.0 Output Formats

• Wiegand (industry standard 26-bit Wiegand

and custom Wiegand formats)

• Magnetic Stripe (ABA Track II, clock and data,

with card present)

6.0 Grounding

Shield (drain) continuity must run from the reader to the access panel.

Shield (drain) and reader ground must be tied together at the access

panel and connect to an earth ground at one point.

7.0 Power

Reader may be powered by the access panel. A linear power supply is

recommended for best operation.

8.0 Voltage and Current

Voltage: 8 to 14 VDC

Current Draw: 60mA typical, 90mA peak

9.0 ﬂeaPower™ Control Line

To reduce the average current required by the reader, pull the purple

conductor low.

10.0 Connection

Connection must be done in accordance with NFPA 70. Do not

connect to a receptacle controlled by a switch. Connect to a power

limited DC voltage source.

11.0 Troubleshooting

1. When the reader is ﬁrst powered on it will beep 4-times, and the

LED will shine red.

2. Presenting a supported access credential will result in the reader

beeping and the LED ﬂashing once.

3. Mobile operation is optimized for smartphones supporting BLE

(Bluetooth LE) version 4.2 or newer. Further, for the downloading

of mobile access credentials, a stable, high-quality internet

connection is recommended.

QUICK ART IDE ST GU

ACCESS CONTROL MO

ILE-READY ROXIMI Y EADERS P T R

This Quick Start Guide is intended for experienced installing technicians. It is a basic reference to ensure all connections are properly made.

Models include . APCR35L, APCR620L and APCR640L

Model Mullion Mount Single-Gang Wall Mount*

APCR35L

APCR35LAPCR35L

• •

APCR620L

APCR620LAPCR620L

•

APCR640L

APCR640LAPCR640L

•
