Sida 1/2
! ITEM : CLPR67H №
! Adjustable function
1. Resistor A: If you want to change the intensity of the IR light, please open
the back cover. And you can adjust it in the tail of the box camera( the
following picture for your reference) is
2. Resistor B: If you want to change the working time of IR Led, please open
the back cover. And you can adjust the working time in the tail of box
camera – (the following picture is for your reference).” “refers to the IR LED
will start working under the darker situation. “+” refers to the IR LED will
start working under the brighter situation.
! Packing
1. Camera X1
2. User Manual X1
3. Screw X3
4. Metal-Conical- X3 Anchor
5. Adaptor X1
6. Hexagonal Wrench X3
7. Mounting drawing paper X1
! Specification
ITEM
CLPR67H
IP Rating
IP66
Type
Monochrome
Signal System
NTSC/PAL
Pick Up Device
1/3" 960H CCD
Picture Elements
NTSC:1020H×508V PAL:1020H 596V×
Resolution
700 TVL
LED
8Pieces Super High Power LED
Vertical Frequency
NTSC:60Hz;PAL:50Hz
Horizontal Frequ ency
NTSC:15.734KHz PAL:15.625KHz
Clock Frequency
NTSC/PAL:36MHz
Scanning System
2:1 Interlace
S/N Ratio
≥52dB
Lens
5-50mm Varifocal Auto Iris IR Lens
Video Out- put
1V p p,75- Ω
Power Supply
DC12V±10%
Current Consumption
15 00mA (with heater and fan)
Recommend Working Distance
5- - 30M （16.3 98.3ft）
Dimension
492 140 260mm 19.37” 5.5” 10.24”× × （× × ）
Weight
2520g (88.8oz)
Storage Temperature
-30～+60 (- 22～+140)
Operating Temperature
-30～+40 (- 22～+104)
Remark: Non aged-regulative adaptor may cause camera dam .
License Plate Capture Camera
! Caution for Installation
1. Please do not install the camera where the vibration always happens, or the
camera will be damaged.
2. Please keep the glass in front of the camera clean. Do not touch it directly.
You can use a soft cloth with alcohol to wipe if necessary.
3. The available IR range of this camera is shown in the specification. Please
be sure to place the camera in the distance when it worksworking .
4. In order to prevent short circuit, please do not loosen any screws in the
camera at random.
5. Please do not let the camera work in the conditions which is beyond the
most extreme and demanding of operating conditions and climates shown
in the specification. When any abnormalities happen, please turn off the
camera and contact your local dealer or us right away.
Pay attention to the setting angle. The picture in the right is for your
reference.
