200 New Highway, Amityville, NY 11701

800-645-5516 / www.specotech.com

FEATURES

4MP Flexible Intensifier® HD-TVI Bullet Camera

with Junction Box, Wall/Ceiling Mount, Dual voltage

H4FB2M

–2.7~12mm motorized zoom focuslens, dark gray housing

SPECIFICATIONS

Image Sensor.................. 1/2.8” SONY Starvis5MP Sensor

Minimum Illumination....... 0.00 lux (IR LED ‘on’)

Effective Pixels................ 2616 (H) x 1964 (V)

Total Pixels...................... 2704 (H) x 2104 (V)

Scanning System............ Progressive

S/N Ratio......................... More than 50dB

Video Output.................... 1.0Vp-p / 75 Ohms

Electronic Shutter............ Auto / Manual (1/30 –1/30,000 sec.)

WDR................................ On (Low / Middle / High) / Off

Day / Night....................... Auto / Intensifier

Test Monitor Output......... TVI out

Power............................. 12VDC / 24VAC

Power Consumption........ 900mA max. (DC), 700mA max. (AC)

Operating Temperature.... -40

°F –140

°F

Unit Dimensions.............. 9.64” (L) x 3.72” (Dia.)

Unit Weight...................... 2 lbs(camera), 0.9 lbs(junction box)

Certifications.................... FCC, RoHS

• Flexible Intensifier Technology

®

fits any lighting application

• Supports 4MP @ 30FPS

• True WDR operation

• Adaptive IR LED’s

• Presets: Outdoor, Low Light, Hallway, Lobby, Elevator, Indoor

• Built-in heater and anti-fog glass reduces condensation

• 3-axis for wall and ceiling mounting

• Full OSD and Zoom / Focus control through on-board and UTC

• Signal distance up to 1600 feet*

• Vandal / tamper resistant

• IP67 compliant, weather resistant

• 12VDC & 24VAC dual voltage operation

• 5 year warranty

OSD MENU TREE

PRESET MODE

•OUTDOOR

•INDOOR

•LOW LIGHT

•LOBBY

•HALLWAY

•ELEVATOR

MAIN SETUP

EXPOSURE

•••LOWMIDDLEHIGH

•••SHARPNESSGAMMAMIRROR

•FLIP

DAY / NIGHT

COLOR

SPECO DNR


EXIT

••BRIGHTNESSSHUTTER

BACKLIGHT

•HLC•BLC

•WDR

•AUTO

••AWBCOLOR GAIN

••ACEDEFOG

SYSTEM

••INTENSIFYAGC

•INTENSIFIER

IRIS

MOTION

•SHADING

•CAMERA TITLE

••COMMIMAGE RANGE

•COLOR SPACE

•OUTPUT

•LANGUAGE

•COLOR BAR

•RESET

OSD CONTROL

•D-ZOOM

•PRIVACY

MOTORIZED

INTCM1

(Pole/Corner Mount)

DIMENSIONS

Camera

Optional Accessories

Unit : inch

Junction Box

included

OSD Joysck

Video Test (TVI OUT)

Right (Near)

Up (Zoom-In)

Down (Zoom-Out)

Le (Far)
