l ITEM №: H5B1M

l Caution for Installation

1. In order to prevent electronic shock,don’ t loosen any screws or covers.

2. Do not directly touch the front glass.If necessary, use a soft cloth

moistened with alcohol to wipe off the dust.

3. Avoid places where there are frequent vibrations or shocks.

4. ’Don t operate the camera beyond its temperature,power source ratings.

5. When any abnormalities happen, make sure to unplug the camera and

contact your local dealer.

l Packing

1. Camera X1

2. User Manual X1

3. Screw X3

4. - - X3 Plastic Conical Anchor

5. agonal WrenchHex X1

6. Mounting drawing paper X1

7. Junction Box X1

8. Power Cable Connector X1

9. Video Line X1

10. Junction box(including accessories) X1

l Specification

ITEM

H 5B1M

IP Rating

IP66

Type

Removable IR Cut Filter

Signal System

NTSC/PAL

Pick Up Device

1/2.8 ” 5M SONY CMOS

Picture Elements

2 688 (H)X1944 (V)

Min Illumination

0 ( ON) Lux 8PCS High Power Led

S/N Ratio

≥50 dB

Lens

2.7 13.5- mm Motorized Varifocal Fixed Iris Lens

Back Light Compensation

OFF

WDR

ON/OFF

OSD

YES

Video Out- put

5MP TVI/AHD,4MP TVI/AHD/CVI,&2MP CVBS

Power Supply

DC12V ±10%

Current Consumption

680mA(MAX)

Dimension

231×84X110mm (9.1”×3.3” ×4.3” )

Weight

28.9oz

Storage Temperature

- 9 22～+14 ℉

Operating Temperature

- 22～+122℉

Remark: Non may cause camera damaged -regulative adaptor .

l video signal output switches

5MP 4 Motorized Bullet Camera with in1 Junction Box

Ø Multi Format HD Analog UTC Control

(1)- Zoom/focus lens menu

(2)- Zoom in

(3)- Enter into camera OSD main menu

(4)- Zoom out

(5)- Main menu operation page

1. Zoom/Focus

As picture shown,Click(1) enter into lens ; menu Click

zoom in zoom out; Click (3); Click enter into camera

OSD main menu.

2. OSD

, c As picture show lick (5) enter into main menu

ge.

(1)

(2)

( 3)

(4)

(5)
