200 New Highway, Amityville, NY 11701
800645--5516 / www.specotech.com
FEATURES
Intensifier® Series HD-TVI 1080p 2MP Dome Camera
Wall/Ceiling Mount, UTC, 2BNC out for TVI & CVBS, Dual voltage
HT7246T2 – 2.8~12mm auto iris lens, dark gray housing
SPECIFICATIONS
Image Sensor.................. 1/” 2.9Progressive Scan CMOS, 2MP
Minimum Illumination....... 0.001 lux (Sens-)up X32
Effective Pixels................ 1984 1105 (H) x (V)
Total Pixels...................... 2000 (H) x 1121 (V)
Scanning System............ Progressive
S/N Ratio......................... More than 50dB
Output Resolution............ 192030fpsx1080 @
Video Output.................... 1.075 Vp-p / Ohms
Electronic Shutter............ Auto / Manual (1/30 – 1/30,000 sec.)
Day / Night....................... Color (default) / BW / External / Auto
Test Monitor Output......... CVBS (Yellow BNC / Connector on Board)
Communication............... UTC (up the coax)
Power............................. 1224VDC / VAC
Power Consumption........ mA max. (DC), 450250mA max. (AC)
Operating Temperature.... -40140°–F ° F
Unit Dimensions.............. 3.975.23” (H) x ” (Dia.)
Unit Weight...................... 1.4 lbs (camera), 0.7 lbs (junction box)
Certifications.................... FCC, RoHS
Signal Distance............... Up to 1600 feet
(depending on coax quality)*
• Full HD resolution over coax (HD-TVI)
• Supports up to Full HD 1080p @ 30fps
• True WDR operation
• Superior lowlight performance -
• Amplify existing light with no distance limitation
• Presets: Outdoor, Low Light, Hallway, Lobby, Elevator, Indoor
• Built--in heater and antifog glass reduces condensation
• 3-axis for wall and ceiling mounting
• Chameleon Cove: snaps on and can be painted to
match any décor!*
• Full OSD operation through onboard control and UTC (up the coax) -
• Additional 960H analog output
• Signal distance up to 1600 feet*
• Vandal / tamper resistant
• IP67 compliant, weather resistant
• 12VDC & 24VAC dual voltage operation
•5 year warranty
OSD MENU TREE
PRESET MODE
• OUTDOOR
• INDOOR
• LOW LIGHT
• LOBBY
• HALLWAY
• ELEVATOR
MAIN SETUP
EXPOSURE
• B/W
• EXTERN
••• LOW MIDDLE HIGH
• SHARPNESS•• GAMMA MIRROR
• FLIP
DAY / NIGHT
COLOR
SPECO DNR
EXIT
• BRIGHTNESS
• SHUTTER
BACKLIGHT
• HLC• BLC
• WDR
• AUTO
•• AWB COLOR GAIN
•• ACE DEFOG
SYSTEM
• OUTPUT
• FREQ.
• IMAGE RANGE
• INTENSIFY
• AGC
• COLOR
IRIS
MOTION
• FRAME RATE
• LANGUAGE• COLOR BAR
• RESET
• CAM TITLE
• PRIVACY
FOCUS ADJ
• COLOR SPACE
• COM.
OSD Joystick
Video Test (CVBS)
Right
Up
Down
Left
OSD CONTROL
Enter
DIMENSIONS
Bottom View
Side View
Optional Accessories
Unit : inch
White Cover
(Included)
Black Cover
(Optional)
INTCM1
(Pole/Corner Mount)
INTWM1
(Wall Mount)
