200 New Highway, Amityville, NY 11701
800-645-5516 / www.specotech.com
DIMENSIONS
FEATURES
Intensifier T® Series HD-TVI 1080p 2MP Turret Camera
Wall/Ceiling Mount, UTC, 2BNC out for TVI & CVBS, Dual voltage
HTINT60TM –2.8~12mm motorized zoom
motorized zoom
motorized zoom
motorized zoom motorized zoom focus
focus
focus
focus focus lens, dark gray housing
lens, dark gray housing
lens, dark gray housing
lens, dark gray housinglens, dark gray housing
HTINT601TA –3.6mm lens, dark gray housing
SPECIFICATIONS
Image Sensor.................. 1/3” Progressive Scan CMOS, 2MP
Minimum Illumination....... 0.001 lux (Sens-up X32)
Effective Pixels................ 1984 (H) x 1105 (V)
Total Pixels...................... 2000 (H) x 1121 (V)
Scanning System............ Progressive
S/N Ratio......................... More than 50dB
Output Resolution............ 1920x1080 @ 30fps
Video Output.................... 1.0Vp-p / 75 Ohms
Electronic Shutter............ Auto / Manual (1/30 –1/30,000 sec.)
Day / Night....................... Auto / Color / BW / External
Test Monitor Output......... CVBS (BNC out in Yellow)
Communication............... UTC (up the coax)
Power............................. 12VDC / 24VAC
Power Consumption........ 150mA (DC), 2W (AC)
Operating Temperature.... -4F –122F °°
Unit Dimensions.............. 4.58” (H) x 5.49” (Dia.)
Unit Weight...................... 1.54 lbs
Certifications.................... FCC, RoHS
Signal Distance............... Up to 1600 feet
(depending on coax quality)*
• Full HD resolution over coax (HD-TVI)
• Supports up to Full HD 1080p @ 30fps
• True WDR operation
• Superior low-light performance
• Amplify existing light with no distance limitation
• Presets: Outdoor, Low Light, Hallway, Lobby, Elevator, Indoor
• Built-in heater and anti-fog glass reduces condensation
• 3-axis for wall and ceiling mounting
• Full OSD operation through on-board control and UTC (up the coax)
• Additional 960H analog output
• Signal distance up to 1600 feet*
• Vandal / tamper resistant
• IP67 compliant, weather resistant
• 12VDC & 24VAC dual voltage operation
• 5 year warranty
OSD MENU TREE
Side View
Front View
Optional Accessories
CVCJBD1
(Junction Box)
INTWM1
(Wall Mount)
Unit : inch
OSD ACCESS
PRESET MODE
•OUTDOOR
•INDOOR•LOW LIGHT
•LOBBY
•HALLWAY
•ELEVATOR
MAIN SETUP
EXPOSURE
•B/W
•EXTERN
•••LOWMIDDLEHIGH
•••SHARPNESSGAMMAMIRROR
•FLIP
DAY / NIGHT
COLOR
SPECO DNR
EXIT
•BRIGHTNESS
•SHUTTER
BACKLIGHT
•HLC•BLC
•WDR
•AUTO
••AWBCOLOR GAIN
••ACEDEFOG
SYSTEM
•OUTPUT
•FREQ.
•IMAGE RANGE
•INTENSIFY
•AGC
•COLOR
•SHADING
IRIS
MOTION
•FRAME RATE
•LANGUAGE
•COLOR BAR
•RESET
•CAM TITLE
•D-ZOOM
•PRIVACY
2-MOTOR
•COLOR SPACE
•COM.
OSD Joystick
Video Test
INTCM1
(Pole/Corner Mount)
