Sida 1/8
SPECO TECHNOLOGIES
PROFESSIONAL SERIES
INSTRUCTION MANUAL
PAT-20TB MOBILE PUBLIC
ADDRESS AMPLIFIER
WITH TALK BACK SYSTEM
Low Hi
PA & TALK BACK AMPLIFIER
MIC
PAT-20TB
ON
OFF
POWER
TONE
AUX VOLUME
Min Max
VOLUME
Min Max
Mic input
3mv/5k
TALK
BACK
PA
ATTENTION INSTALLER
BEFORE INSTALLING THIS EQUIPMENT,PLEASE READ THE
INSTRUCTION MANUAL THOROUGHLY. IF YOU ARE NOT
TOTALLY FAMILIAR WITH THE INSTALLATION OF THIS TYPE
OF APPARATUS, PLEASE SECURE THE ASSISTANCE OF A
QUALIFIED TECHNICIAN. IF THE UNIT IS NOT CONNECTED
PROPERLY, DAMAGE MAY RESULT AND YOUR WARRANTY
MAY BE VOIDED.
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK.
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
This symbol is intended to alert the user to the
presence of uninsulated "dangerousvoltage"
within the product's enclosure that may be of
sufficient magnitude to constitute a risk of
electric shock to persons.
This symbol is intended to alert the user to the
presence of important operation and mainte-
nance (servicing) instructions in the literature
accompanying the appliance.
Caution: To prevent electric shock do not use this (polarized)
plug with an extension cord, receptacle or other
outlet unless the blades can be fully inserted to
prevent blade exposure.
Attentions: Pour pr venir les chocs lectriques ne pas utiliser
cette fiche polaris e avec un prolongateur, une
prise de courant on une autre sortie de courant,
sauf si les lames peuvent tre ins r ss fond
sans en laisser aucune partie d couvert.
* *
*
* * * &
& *
WARNING
To prevent fire or shock hazard, do not
expose the unit to rain or moisture.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
Your mobile P.A. AMPLIFIER has been designed using the latest electronic
technology available. This technology allows you to control the P.A. volume
separately for Microphone or Auxiliary inputs. Your unit also comes with a tone
control that allows you to adjust the frequency response.
CAUTION : Before installation/operation read your manual
completely.
SPECIFICATIONS
POWER OUTPUT : 20 WATTS RMS (EXT)
TALK BACK POWER OUTPUT : 4 WATTS RMS (INSIDE SPEAKER)
OUTPUT IMPEDANCE : 4 or 8 OHMS
TOTAL HARMONIC DISTORTION : Less than 1% at 10 Watts output
FREQUENCY RESPONSE : 50Hz - 20KHz Within -3dB
TONE CONTROL : 0-12dB ADJUSTABLE AT 10 KHz
AUX INPUT SENSITIVITY : 200mV/10K ohms
MIC INPUT SENSITIVITY : 2.5mV/5K ohms
SIGNAL TO NOISE RATIO : More than 70dB
POWER SOURCE : 11V TO 16V DC NEG GND
FUSE : 3A
DIMENSION : 5 1/8"(W) X 1 1/4"(H) X 4 1/2"(D)
WEIGHT : 2 lbs.
1
