SBPMJ Parapet Mount Bracket Installaon Instrucons
Box Contents:
1 Parapet Mount and Base
1 PC x Hex Wrench for Seng Screws
6 Sets x Mounng Bolts with Expansion Anchors 63mm±0.5mm (Total Length)
9 PCS x Seng Screws Ø 6mm±0.2mm
Note: The mount shou be installed on a flat and sturdy surface. The installaon surface ld
should be capable of withstanding heavy winds and at least 3 mes the total weight of the
camera being installed.
1. Start by marking off holes in which you want to posion the mount.
2. Drill a hole in the base material with a hammer drill and a correctly sized carbide drill
bit for the anchor. See gure A.
3. Using the proper diameter and use bit, drill holes for the expansion bolts. The depth
of the hole should accommodate the length of the bolt up to the shim.
4. Clean out the hole of all debris.
5. Insert th Expansion Anchor Sleeve with bolt into the hole and ensure the sleeve is e
ush with the surface. See gure B.
6. See the mount base over the single expansion anchor, insert at washer, locking washer
and then tighten the nut of the expansion bolt. The anchor of the bolt will expand
inside the hole and lock into place. Do this for all 6 expansion bolts. See Figure C.
7. Make the camera connecons through the hollow arm and mount the camera to the
arm using the mounng collar and set screws.
8. Insert the arm to the base and use locking screws included to lock this arm in place.
① mounng holes for Metal Plate
② seng holes to x Metal Plate and Tube
Dimensions:
Tolerance ±3mm
Instrucons and specicaons are subject to change without noce.
