Sida 1/3
! ITEM : №VLDT4W/VLDT4G
! Caution for Installation
1. In order to prevent electronic shock, don t loosen any screws or covers.’
2. Do not directly touch the front glass. If necessary, use a soft cloth
moistened with alcohol to wipe off the dust.
3. Avoid places where there are frequent vibrations or shocks.
4. ’Don t operate the camera beyond its temperature, power source
ratings.
5. When any abnormalities happen, make sure to unplug the camera and
contact your local dealer.
! Packing
1. Camera X1
2. Junction box X1
3 . User Manual X1
4. PWA 4*25 Screw X3
5. KM 4*10 Screw X3
6. PM 4*12 Screw X4
7. Junction box cotton pad X1
8. Camera cotton pad X1
9. Ф8.3mm rubber ring X3
10. Plastic Anchor- -Conical X3
11. Hexagonal Wrench X1
12. Mounting drawing paper X1
! Specification
ITEM
VLDT4W/VLDT4G
IP Rating
IP66
Type
Removable IR Cut Filter
Signal System
NTSC/PAL
Pick Up Device
1/2.9" 2.2 Mega Pixels CMOS
Picture Elements
1920(H)X1080(V)
Min Illumination
0Lux with IR LED 12 pieces
S/N Ratio
≥52dB
Lens
3.6mm Board Lens
3D/2D
ON
SENS- UP
ON
IR SMART
ON
White Balance
ATW
Back Light Compensation
OFF
DWDR
ON/OFF
OSD
With UTC Signal(DVR Control OSD)
Video Out- put
HD CVI/ CVBS- - -TVI/HD AHD/HD
Power Supply
DC12V ±10%
Current Consumption
400mA（MAX）
IR Effect Distance
49.2ft (Outdoor)
Dimension
3.7” 3.15”× inch
Camera Weight
330g (11.64oz)
Storage Temperature
- 22～+140
Operating Temperature
- 22～+104℉
Junction box
Dimension
3.7” 1.77×” inch
Weight
230g (8.1oz)
Remark: Non may cause camera damaged -regulative adaptor .
Multi- Format HD Analog IR Camera
!video signal output switches
●Overview
Junction box cotton pad
M20 Plastic Screw
Junction box
Water-proof
rubber ring
Junction box upper cover
KM4*10 threaded
screws
●Installation
（ ）1
（ ）2
（ ）3
（ ）4
（ ）5
（ ）6
1．Drill installation holes according to drawing paper，
then stuff into rubber stoppers。
2．Paste cotton pad onto the bottom of junction
box，then push the water-proof rubber ring onto the
upper body of junction box。
3．Use 3pcs PWA4*25 -self tapping screws to fix
junction box body。
4．Use 3pcs KM4*10 threaded screws to fix
the upper cover with the junction box body。
5．Disassemble the dome base， put the
cotton pad onto the upper cover，then use
4pcs PM4*12 screws to fix the dome base
with the junction box。
6．Connect all cables and
put them into the junction
box ， then install the
dome with the dome base
well， then use the dome
ring to fix。
