VLED23T7G Series Color
Camera
2.5" IR Turret Camera
2.5" IR Turret Camera2.5" IR Turret Camera
2.5" IR Turret Camera
Specifications
Note:Before applying power to the cam-
era, please read this UserGuide in detail.
Model VLED23T7G
Pick-up Device 1/3" Sony Super HAD CCD
Effective Pixels (H×V) NTSC:510×492, PAL:500×582
Sensing Area 4.9mm×3.7mm
Horizontal Resolution 480 TV Lines
Minimum Illumination 0.1 Lux, 0 Lux at IR on
S/N Ratio More than 48dB
Scanning System 2:1 Interlace
Synchronous System Internal
Electronic Shutter 1/50s(1/60s)
1/100,000s
IR Distance 65’
IR Leds 24 pcs Φ5 infrared LED
IR status IR on: under 10Lux, by CDS auto control
Water Resistance IP66
Gama Characteristic 0.45
Auto Gain Control Auto
White Balance Auto
Video Output 1.0Vp-p composite video, 75Ω
Lens 3.6mm
Power/Current 12VDC/ IR on: 300mA, IR off: 100mA
Operating Temperature 14F122F
Storage Temperature -4F 140F
INTRODUCTION
* Sensor (CCD)
SONY 1/3" High Resolution CCD sensor.
* Auto Gain Control (AGC)
Built-in auto gain control circuit. The color camera (AGC)
can get a high definition picture in low Lux condition.
* Auto Electronic Shutter (AES)
Built-in auto electronic shutter function. The AES speed
can reach s. 1/100,000
* Gamma Characteristic
Camera Gama characteristic is 0.45.
* Night-time Vision
0 Lux with IR LED ON.
Monitor
TROUBLESHOOTING
Link wire rule
Power
Video
The symbol is intended to alert the user to the presence of
The symbol is intended to alert the user to the presence of
important operating and maintenance (servicing)
Instructions in the literature accompanying the appliance.
uninsulated ‘dangerous voltage’ within the product’s
enclosure that may be of sufficient magnitude to constitute
a risk of electric shock to persons.
Video
12V DC
CAUTION:
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK
DO NOT REMOVE COVER. NO USER
SERVICEABLE PARTS INSIDE. REFER SERVICING
DO NOT OPEN
CAUTION:
To prevent electric shock and risk of fire hazards,
do NOT use anything other than the specified power
1. No picture after providing power
. Check the power supply voltage, it may be outside specification.
. Please check the connecting cables and monitors to determine if the
camera is connected correctly or not.
2. The picture has flowing interference ripples
. Check the ground of the monitor and other peripheral equipment that
are being used is the same ground as the camera.
3. The background color continuously changes
. A fluorescent bulb’s electromagnetic field can cause a color roll. This is
a proper phenomenon of the camera.
. To improve the image, try to increase the distance between the camera
and the bulb, or change the angle such that it doesn’t face the flores-
cent bulb.
Congratulations on your purchase of this Speco prod-
uct. This camera utilized the latest in SONY sensors
and drivers The most appealing characteristics of .
this camera are weather-resistance, day & night fea-
ture, and indoor & outdoor applications. This product
is a great addition to your CCTV system.
Please read this manual carefully to ensure proper
use of the product.
Installation Precautions:
● Do not install the camera to extreme temperature conditions.
Only use the camera under conditions where temperature
is between 14f and 122f.
● Never keep the camera pointed directly at the sun or a bright
object.
● Do not mount the camera near a radiator or heater.
●The power supply must be regulated 12V supply.
●The operating temperature must be within camera’s specifications.
●For better image quality, the cable length for power and video output
should not be excessively long.
