Sida 1/18

Model 2591

Manual

MixDream XP

Analog 16:2 summing unit

Output

Mono Mono Mono Mono

1/2 3/4 5/6 7/8

Model

2591

POWER

Variable

Output Mono Mono Mono Mono

9/10 11/12 13/14 15/16 Expansion

Input

Discrete Cla ss A

16 in 2 sum ming mixe r

MixDream XP

Manual MixDream XP

Model 2591

Version 1.0, 5/2005

Designer: Ruben Tilgner

This manual contains a description of the product. It in no way

represents a guarantee of particular characteristics or results

of use. The information in this document has been carefully

compiled and verified and, unless otherwise stated or agreed

upon, correctly describes the product at the time of packaging

with this document.

Sound Performance Lab (SPL) continuously strives to improve

its products and reserves the right to modify the product

described in this manual at any time without prior notice. This

document is the property of SPL and may not be copied or repro-

duced in any manner, in part or fully, without prior authorization

by SPL.

CE Declaration of Conformity

Manufacturer: SPL electronics GmbH

Type of Equipment: Audio Signal Processor

Product: MixDream XP, Model 2591

Compliance Engineer: Wolfgang Neumann

Test Basis:

EN 50081-1:1992, EN 50082-1:1992, EN 60065:1993 , EN 61000-

3-3:1995, EN 60065:2002, EN 55013:2001, EN 55020:2002,

EN 61000-3-2:2000, 73/23 EWG; 93/68 EWG.

We herewith declare, that the construction of the MixDream XP,

model 2591, is in compliance with the standards and regulations

mentioned above.

SPL electronics GmbH

Sohlweg 55, 41372 Niederkruechten, Germany

Tel. +49 216 398 340, Fax +49 216 398 3420

EMail: info@soundperformancelab.com

Internet: www.soundperformancelab.com

and their products are trademarks of their respective owners.

MixDream XP 3

Introduction .................................................................... 4

Analog vs. Digital Summing ............................................ 4

Advantages And Special Features ................................... 5

MixDream XP Advantages—An Overview ......................... 5

Connection of Samplers, Keyboards etc. ......................... 5

Mono Switches ................................................................ 5

Before You Begin ............................................................ 6

Rear Panel/Connections ................................................. 7

Wiring ............................................................................. 7

General advices .............................................................. 8

Input Channels ................................................................ 9

Main Outputs ......................................................................

Monitor Outputs ............................................................. 9

Control Elements ............................................................ 10

Output Control ................................................................ 10

Variable Output Switch ................................................... 10

Mono Switch ................................................................... 10

Expansion Input Switch ................................................... 10

GND-Lift Switch ............................................................... 11

Applications and Modes of Operation ............................. 11

Summing ........................................................................ 11

Summing of Subgroups ................................................... 11

MixDream XP in Mastering Applications ........................... 12

Linking Several MixDream XP ........................................... 12

Linking Several MixDream XP/Diagram ............................ 13

Block Diagram ................................................................. 14

Measurements ................................................................ 15

Power Supply .................................................................. 16

Specifications, Dimensions and Weight ........................... 17

Warranty ......................................................................... 18

Contents
