MODEL SR810
DSP Lock-In Amplifier
129
0-D Reamwood Avenue
Sunnyvale, California 94089
Phone: (408) 744-9040 • Fax: (408) 744-9049
email: info@thinkSRS.com • www.thinkSRS.com
Copyright © 1993, 2000, 2005 by SRS, Inc.
All Rights Reserved.
Revision 1.8 (01/2005)
Table of Contents
1-1
GENERAL INFORMATION
Safety and Preparation for Use
1-3
Specifications 1-5
Abridged Command List
1-7
GETTI
NG STARTED
Your First Measurements
2-1
The
Basic Lock-in
2-2
X and R
2-5
Outputs, Offsets and Expands
2-7
Storing and Recalling Setups
2-10
Aux Outputs and Inputs
2-11
SR810 BASICS
What is a Lock-in Amplifier?
3-1
What Does a Lock-in Measure?
3-3
The SR810 Functional Diagram
3-4
Reference
Channel 3-5
Phase Sensitive Detectors 3-7
Time Constants and DC Gain
3-8
DC Outputs and Scaling
3-10
Dynamic
Reserve
3-12
Signal Input Amplifier and Filters
3-14
Input
Connections 3-16
Intrinsic (Random) Noise Sources 3-18
External Noise Sources
3-20
Noise Measurements 3-22
OPERATI
ON
Power On/Off and Power On Tests
4-1
Reset
4-1
[Keys]
4-1
Spin
Knob
4-1
Local
Lockout 4-2
Front Panel BNC Connectors
4-2
Key Click On/Off 4-2
Front Panel Display Test
4-2
Display Off Operation
4-2
Keypad
Test
4-3
Standard Settings 4-4
FRONT PANEL
Signal Input and Filters 4-5
Sensitivity, Reserve, Time Constants 4-7
CH1 Display and Output
4-12
Reference 4-15
Auto
Functions
4-18
Setup 4-20
Interface 4-21
Warning
Messages
4-23
REAR PANEL
Power Entry Module
4-24
IEEE-488
Connector
4-24
RS-232
Connector
4-24
Aux Inputs (A/D Inputs) 4-24
Aux Outputs (D/A Outputs) 4-24
X and Y Outputs
4-24
Signal
Monitor Output
4-25
Trigger
Input 4-25
TTL Sync Output
4-25
Preamp
Connector
4-25
Using SRS Preamps
4-26
PROGRAMMI
NG
GPIB Communications
5-1
RS-232
Communications
5-1
Status Indicators and Queues
5-1
Command
Syntax
5-1
Interface Ready and Status
5-2
GET (Group Execute Trigger)
5-2
DETAI
LED COMMAND LIST
5-3
Reference
and Phase
5-4
Input and Filter 5-5
Gain and Time Constant 5-6
Display and Output
5-8
Aux Input and Output
5-9
Setup 5-10
Auto
Functions
5-11
Data
Storage
5-12
Data
Transfer
5-15
Interface 5-20
Status
Reporting
5-21
STATUS BYTE DEFI
NITIONS
Serial Poll Status Byte
5-23
Service
Requests 5-24
Standard Event Status Byte 5-24
LIA Status Byte
5-25
Error
Status Byte
5-25
PROGRAM EXAMPLES
Microsoft C, Nationall Instr GPIB
5-27
USING SR510 PROGRAMS 5-31
TESTING
Introduction
6-1
Serial
Number
6-1
Firmware
Revision
6-1
Preset 6-1
Warm
Up
6-1
Test
Record 6-1
If A Test Fails
6-1
Necessary
Equipment
6-1
Front Panel Display Test
6-2
Keypad
Test
6-2
