Sida 1/2

• 1xDisplayPort/MiniDisplayPorttoDVIActive

Converter

• DisplayPortenabledcomputersystem/videocard**

• DVI-D(digital)enableddisplaydevice(i.e.monitor,

projector,HDTV,etc.)

**compatiblewithbothMulti-modeDisplayPort(DP++)andSingle-mode

DisplayPortvideocards,suchasAMDEyenity

1.Makesurethevideodisplaydevice(i.e.monitor,projector,HDTV,etc.)isturnedoff,beforeconnectingto

theadapter.

2.Connectastandardmale/maleDVI-Dcablefromtheconverteradaptertothevideodisplaydevice.

3.Turnonthevideodisplaydevice.

4.ConnecttheMiniDisplayPortconnectorontheconverteradaptertothevideosourcedevice(i.e.

computer,laptop,etc.).Thecomputercanbeonoroff,asitshouldbeabletoautomaticallydetectand

conguretheadapteranddisplaydevice(refertodocumentationthatcamewiththecomputer).

5.Oncetheexternaldisplayisdetectedandcongured,thevideooutputshouldbevisibleonthedisplay

device.Someadjustmentsmaybenecessaryfromthevideosourcedevicesoutputsettingsforoptimal

viewing.

ManualRevision:11/12/2010

Forthemostup-to-dateinformation,pleasevisitwww.startech.com

TheDisplayPorttoDVISingle-LinkActiveConverters

letsyouconnectyourDisplayPortvideosource(PC,

Mac,laptop,etc.)toaDVI-Ddisplay(televisions,

AppleCinemaDisplayHD),eliminatingtheexpense

ofhavingtoupgradetoaDisplayPortcapable

monitor.

Unlikepassiveadapters,thisdeviceoffersanactive

conversionforusewithanyDisplayPortoutput

-idealforgraphicscardsthatarenotcapableof

outputtingmulti-modeDP++signals(e.g.AMD

Eyenity).Supportingresolutionsupto1920x1200,

thiscompactdeviceprovidesasimplesolutionfor

adaptingPCorMacMini-DisplayPortoutputfor

compatibilitywithexistingDVImonitors,televisions

orprojectors.

*actualproductsmayvaryfromphotos

Warranty Information

Thisproductisbackedbyaoneyearwarranty.

Inaddition,StarTech.comwarrantsitsproductsagainstdefectsinmaterials

andworkmanshipfortheperiodsnoted,followingtheinitialdateofpurchase.Duringthisperiod,theproductsmaybereturnedforrepair,orreplacementwith

equivalentproductsatourdiscretion.Thewarrantycoverspartsandlaborcostsonly.StarTech.comdoesnotwarrantitsproductsfromdefectsordamagesarising

frommisuse,abuse,alteration,ornormalwearandtear.

Limitation of Liability

InnoeventshalltheliabilityofStarTech.comLtd.andStarTech.comUSALLP(ortheirofcers,directors,employeesoragents)foranydamages(whetherdirect

orindirect,special,punitive,incidental,consequential,orotherwise),lossofprots,lossofbusiness,oranypecuniaryloss,arisingoutoforrelatedtotheuseof

theproductexceedtheactualpricepaidfortheproduct.Somestatesdonotallowtheexclusionorlimitationofincidentalorconsequentialdamages.Ifsuchlaws

apply,thelimitationsorexclusionscontainedinthisstatementmaynotapplytoyou.

FCC Compliance Statement

ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice,pursuanttopart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonable

protectionagainstharmfulinterferenceinaresidentialinstallation.Thisequipmentgenerates,usesandcanradiateradiofrequencyenergyand,ifnotinstalledandusedinaccordancewith

theinstructions,maycauseharmfulinterferencetoradiocommunications.However,thereisnoguaranteethatinterferencewillnotoccurinaparticularinstallation.Ifthisequipmentdoes

causeharmfulinterferencetoradioortelevisionreception,whichcanbedeterminedbyturningtheequipmentoffandon,theuserisencouragedtotrytocorrecttheinterferencebyoneor

moreofthefollowingmeasures:

• Reorientorrelocatethereceivingantenna.

• Increasetheseparationbetweentheequipmentandreceiver.

• Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiver

 isconnected.

• Consultthedealeroranexperiencedradio/TVtechnicianforhelp.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-party companies not related in any way to

StarTech.com.WheretheyoccurthesereferencesareforillustrativepurposesonlyanddonotrepresentanendorsementofaproductorservicebyStarTech.com,oranendorsementofthe

product(s)towhichthismanualappliesbythethird-partycompanyinquestion.Regardlessofanydirectacknowledgementelsewhereinthebodyofthisdocument,StarTech.comhereby

acknowledgesthatalltrademarks,registeredtrademarks,servicemarks,andotherprotectednamesand/orsymbolscontainedinthismanualandrelateddocumentsarethepropertyof

theirrespectiveholders.

DP2DVIS MDP2DVIS

Video Signal DisplayPort1.1a

DVI-D(DDWG1.0)

Connectors 1xDisplayPortmale

1x25-pinDVI-Dfemale

1xMiniDisplayPortmale

1x25-pinDVI-Dfemale

Maximum Video

Resolution 1920x1200

HDCP Support Yes

Operating Temperature 0°C~70°C(32°F~158°F)
