Sida 1/3

3ft (1m) Mini DisplayPort Cable - 4K x 2K Ultra HD Video - Mini DisplayPort 1.2 Cable - Mini DP to

Mini DP Cable for Monitor - mDP Cord works w/ Thunderbolt 2 Ports - White

Product ID: MDPMM1MW

The MDPMM1MW 1m White Mini DisplayPort 1.2 cable features 2 Mini DP male connectors, and oers a

dependable solution for connecting any Mini DisplayPort-enabled laptop (including Mac family of products) to a Mini

DisplayPort-equipped monitor.

The mDP cable supports high resolutions of up to 4k x 2k (3840 x 2160) @ 60Hz with a maximum HBR2 bandwidth

of 21.6 Gbps. The cable also supports Multi-Stream (MST) for daisy chaining multiple monitors and provides optional

audio support.

The MDPMM1MW is backed by StarTech.com’s Lifetime Warranty, for guaranteed reliability and ensures that digitally

protected content is displayed properly, with both HDCP and DPCP capability.

Please note: Newer laptop and desktop computers (e.g. Apple) come equipped with Thunderbolt ports only. Our Mini

DisplayPort Cables can be connected to the Thunderbolt ports, enabling you to connect your Mini DP compatible

displays.

Certications, Reports and Compatibility

Applications

• Connecting your Mini DisplayPort products to a Mini DisplayPort compatible display

Features

• MINI DISPLAYPORT 1.2 CABLE: This 3.3 ft (1m) Mini DisplayPort v1.2 cable supports 4K x 2K (3840x2400p

60Hz), 21.6 Gbps bandwidth , HBR2, 8Ch Audio, Multi-Stream Transport (MST), GTC for precise audio channel

timing & 3D Stereo (2560x1600p 120Hz)

• RELIABLE DESIGN: Durable ABS connectors with exible PVC strain relief and jacket prevents fraying or damage

due to bending or rough usage; Metal connector sub-structure provides EMI shielding; Mini DisplayPort cable works

with Thunderbolt 2 ports

• QUALITY CONSTRUCTION: 30AWG wire with gold-plated connectors for improved signal integrity & reliability;

Superior EMI shielding with double sided copper foil provides higher quality video and audio; mDP cable is

backwards compatible with DP 1.1

• APPLICATIONS: Ideal for home/oce/boardroom/classroom works w/laptop (with TB2/Mini-DP port)/professional

workstations with FirePro W9100/8100, NVS 810/510 graphic card; UHD/4K monitor/projector/display; Apple

MacBook Pro/Air, Microsoft Surface Pro 1-6

• SPECS: 3.3 feet (1 meter) White Mini DisplayPort Cable DisplayPort v1.2 Mini-DP Male to Mini-DP Male Cord 30

AWG PVC cable jacket, ABS connector shell Shield: Al-Mylar foil with Braid Protocols: HBR 2, MST, GTC

Hardware

Warranty

Lifetime

Number of Conductors

Connector Plating

Gold

Cable Jacket Material

PVC - Polyvinyl Chloride

Cable Shield Material

Aluminum-Mylar Foil with Drain

Fire Rating

CMG Rated (General Purpose)

Performance

Maximum Digital

Resolutions

4k x 2k (3840 x 2160) @ 60Hz

Connector(s)

Connector A

Mini-DisplayPort (20 pin)

Connector B

Mini-DisplayPort (20 pin)

Physical

Characteristics

Color

White

Wire Gauge

32 AWG

Cable Length

39.4 in [100 cm]

Product Length

39.4 in [100.0 cm]

Product Width

0.4 in [10.0 mm]

Product Height

0.3 in [8.0 mm]

Weight of Product

1.5 oz [43.0 g]

Packaging

Information

Package Quantity

Package Length

7.9 in [20.0 cm]

Package Width

8.7 in [22.0 cm]

Package Height

0.4 in [10.0 mm]

Shipping (Package)

Weight

1.5 oz [43.0 g]

What's in the Box

Included in Package

1 m White Mini DisplayPort 1.2 Cable - M/M

*Product appearance and specications are subject to change without notice.

Produktspecifikationer

Varumärke:	StarTech.com
Kategori:	kabel för dator och kringutrustning
Modell:	MDISPLPORT3
Vikt:	34 g
Höjd:	10 mm
Förpackningens bredd:	200 mm
Maximal upplösning:	3840 x 2400 pixlar
DisplayPort-version:	1.2
Bandbredd:	21600 MB/s
Anslutning 1:	mini DisplayPort
Anslutning 2:	mini DisplayPort
Antal ledare:	19
Kabellängd:	0.9 m
Produktens färg:	Svart
Låddjup:	220 mm
Vikt inkl. förpackning:	44 g
Ytterförpackningens höjd:	235 mm
Produkter per ytterförpackning:	100 styck
Ytterförpackningens längd:	501 mm
Ytterförpackningens bredd:	322 mm
Temperatur vid drift:	-20 - 50 ° C
Temperaturintervall (förvaring):	-20 - 60 ° C
Intervall för relativ operativ luftfuktighet:	0 - 75 %
Plätering på anslutningskontakter:	Nickel
Max uppdateringsfrekvens:	60 hz
Typ, kontakt 1:	Hankoppling
Typ, kontakt 2:	Hankoppling
Jacka material:	Polyvinylklorid (PVC)
AWG kabelstorlek:	32
Anslutning 1, formfaktor:	Rak
Anslutning 2, formfaktor:	Rak
Kabelmärkning:	CMG (CM)
MST (Multi Stream Transport):	Ja
