Sida 1/2
Quick-start guide
FR: Guide de l’utilisateur - fr.startech.com
DE: Bedienungsanleitung - de.startech.com
ES: Guía del usuario - es.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
IT: Guida per l’uso - it.startech.com
Manual Revision: 07/15/2016
For the latest information, technical specications, and support for
this product, please visit www.StarTech.com/PEX10000SRI.
Package contents
• 1 x 10G SFP+ ber network card
• 1 x 10GBase-SR SFP+ transceiver module (preinstalled)
• 1 x low-prole bracket
• 1 x quick-start guide
System requirements
• PCI Express® enabled computer with an available PCI Express slot
(x8 or x16)
• Any of the following operating systems:
• Windows® 10 (32-bit and 64-bit)
• Windows 8.1 (32-bit and 64-bit)
• Windows 8 (32-bit and 64-bit)
• Windows 7 (32-bit and 64-bit)
• Windows Server® 2008 R2
• Windows Server 2012
• Linux® Kernel 2.6.24 and later
• Microsoft® Hyper-V®
• Phillips head screwdriver (optional)
System requirements are subject to change. For the latest
requirements, please visit www.StarTech.com/PEX10000SRI.
PEX10000SRI
1-Port 10G SFP+ Fiber Optic Network Card - PCIe - Intel Chip - MM
Introduction
To experience reliable high-performance network connectivity over
multi-mode ber, you can use the PEX10000SRI to add a 10GBase-SR
port to your server or workstation. This SFP+ network card oers up
to 10Gbps of network speed and features the Intel® 82599 chipset.
The PEX10000SRI can be mounted in both low-prole and full-prole
computer systems.
Product diagram
SFP+ slot
Link or activity LED
Mounting bracket
(full-prole pictured)
PCIe p1-x8
connector
*actual product may vary from photos
Bracket screw
Bracket screw
Install the low-prole bracket
The PEX10000SRI can be mounted in both low-prole and
full-prole computer systems. The full-prole bracket comes
preinstalled, but you can install the low-prole bracket instead.
1. Remove the from the 10GBase-SR SFP+ transceiver module
SFP+ slot on the SFP+ network card.
2. Use a Phillips head screwdriver to remove the two bracket screws
from the PEX10000SRI.
3. Remove the full-prole bracket from the SFP+ network card.
4. Line up the low-prole bracket with the bracket holes on the back
of the SFP+ network card.
5. Insert the two bracket screws that you removed in step 2 and
tighten them into place.
6. Insert the into the 10GBase-SR SFP+ transceiver module SFP+
slot on the network card
Install the network card in a computer
Warning! PC components can be severely damaged by static
electricity. If an anti-static strap isn’t available, discharge any built-
up static electricity by touching a large, grounded metal surface for
several seconds.
1. Turn o your computer and any devices or peripherals that are
connected to it (for example, printers, external storage, and
so on).
10GBase-SR SFP+
transceiver module
