Quick start guide

FR: Guide de l’utilisateur - fr.startech.com

DE: Bedienungsanleitung - de.startech.com

ES: Guía del usuario - es.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

IT: Guida per l’uso - it.startech.com

Manual Revision: 10/14/2015

For the latest information, technical specications, and support for

this product, please visit www.startech.com/SDOCKU313E.

Packaging contents

• 1 x USB 3.1 and eSATA SSD and HDD docking station

• 1 x universal power adapter (NA/EU/UK/AU)

• 1 x USB cable

• 1 x eSATA cable

• 1 x quick start guide

System requirements

• Computer system with an available USB Type A port or an eSATA

port

• A 2.5 in. or 3.5 in. SATA hard drive (HDD) or solid-state drive (SSD)

The SDOCKU313E is OS independent and doesn’t require any

additional drivers or software.

Note: To obtain the maximum USB throughput, you must use a

computer with a USB 3.1 Gen 2 (10Gbps) port.

System requirements are subject to change. For the latest

requirements, please visit www.startech.com/SDOCKU313E.

SDOCKU313E

USB 3.1 (10Gbps) and eSATA Docking Station for SATA Drives

*actual product may vary from photos

Product diagram

Front view

Power button and LED

Drive slot

Eject button

Rear view

DC power connector

USB 3.1 type B

connector (host)

eSATA connector

Installation

Connect the dock

Warning! Drives and storage enclosures should be handled carefully,

especially when they’re transported. If you’re not careful with your

drives, you may lose data as a result. Always handle storage devices

with caution.

1. Connect the external power adapter from the dock to a power

outlet.

2. Do one of the following:

• Connect the included USB cable from the dock to a USB port on

your computer system. Your computer can either be turned on

or turned o when you connect the USB cable.

• Connect the included eSATA cable from the dock to an eSATA

port on your computer system. Your computer can either be

turned on or turned o when you connect the USB cable.

Install a drive

Before you install a drive, make sure that the dock is turned o.

1. Carefully align a 2.5 in. or 3.5 in. SATA drive with the drive slot on

the dock, so that the SATA power and data connectors on the

drive are aligned with the corresponding connectors that are

inside of the drive slot.

2. Insert the 2.5 in. or 3.5 in. SATA drive into the slot.

3. Press the Power button to turn on the dock. The LED indicator

should light up to indicate that the dock is turned on.

After the drive is installed and the dock is turned on, your computer

automatically recognizes the drive and it’s accessible as though the

drive is installed internally in the system. If your computer doesn’t

automatically recognize the drive, see the Prepare a drive for use

topic.

About driver installation

No driver or software installation is required for this product because

the dock is natively supported and the drivers are already installed.

Produktspecifikationer

Varumärke:	StarTech.com
Kategori:	Vagga/dockningsstation
Modell:	SDOCKU313E
Vikt:	410 g
Bredd:	93 mm
Djup:	145 mm
Höjd:	63 mm
Förpackningens bredd:	161 mm
LED-indikatorer:	Activity, Power
Inbyggd fläkt:	Nej
Certifiering:	CE, FCC, REACH
Material:	Plast
Typ av lagringsmedia:	HDD, SSD
Uteffekt:	2 A
Snabbinstallationsguide:	Ja
Värdgränssnitt:	USB 3.2 Gen 2 (3.1 Gen 2) Type-B
Maximal lagringskapacitet:	6 TB
Antal lagringsenheter som stöds:	1
Produktens färg:	Svart
Låddjup:	171 mm
Vikt inkl. förpackning:	862 g
Ytterförpackningens höjd:	184 mm
Produkter per ytterförpackning:	10 styck
Ytterförpackningens längd:	484 mm
Ytterförpackningens bredd:	382 mm
Typ av strömkontakt:	Typ M
Temperatur vid drift:	5 - 35 ° C
Temperaturintervall (förvaring):	-20 - 50 ° C
Intervall för relativ operativ luftfuktighet:	20 - 80 %
Hållbarhetscertifiering:	RoHS
Utgångsspänning:	12 V
AC-inspänning:	110-240 V
Kabel inkluderad:	USB, eSATA
Likströmsingång:	Ja
AC-adapter inkluderad:	Ja
Plug & Play-kompatibel:	Ja
Harmonized System (HS)-kod:	84733080
Ingående ström:	0.6 A
Kretsar:	ASMedia - ASM1351
Lagringsenhetens gränssnitt:	Serial ATA, Serial ATA II, Serial ATA III
Storlekar som stöds på lagringsenhet:	2.5, 3.5 "
Maximal överföringshastighet:	10 Gbit/s
Stöd för UASP:	Ja
Typer av nätkontakter som ingår:	AU, EU, NA, UK
Byte under drift (hotswap):	Ja
Antal eSATA portar:	1
