Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: March 31, 2020 9:44 AM
Product Diagram (TB3DKM2HDL)
Component Function
1Thunderbolt 3 Host
Connector
• Connect the to the Docking Station Host
Laptop.
2HDMI Ports x 2 • Connect an to the HDMI Display Device
Docking Station.
• Two or can be HDMI 4K Display Devices
connected to the .Docking Station
3USB 3.0 Port
• Connect a (mouse, ash drive, USB Peripheral
etc.) to the .Docking Station
• Data transfer up to 5Gbps.
4USB 2.0 Port
• Connect a (mouse, ash drive, USB Peripheral
etc.) to the .Docking Station
• Data transfer up to 480Mbps.
5RJ45 Port • Connect a to the Network Device Docking
Station.
Requirements
For the latest requirements, please visit www.startech.com/TB3DKM2HDL
• Host Laptop w/ Thunderbolt 3 port x 1
• HDMI Display Device x 2
Notes: A 4K-capable display is required to achieve 4096 x 2160p resolution.
Video output capabilities are dependent on the video card and hardware specications of
your connected host laptop.
You can connect a dierent type of display, such as a DisplayPort or VGA monitor using
an active video adapter (sold separately):
Thunderbolt™ 3 Dual HDMI Mini Bus Powered Docking Station for Laptops | 4K 60Hz | 28 cm Cable
• HDMI Cables x 2
Operating System:
• Windows® 10, 8, and 8.1
• macOS 10.13 and 10.12
Installing the Docking Station
When you connect the Docking Station to a computer that’s running Windows 10,
Windows 8/8.1 or macOS, the required drivers are automatically installed.
1. Connect an (sold separately) to the on the HDMI Cable HDMI Port Docking Station
and the other end to an HDMI port of a .Display Device
2. Repeat step 1 to connect a second .Display Device
3. Connect a to the and on the USB Peripheral Device USB 3.0 USB 2.0 Ports
Docking Station (e.g. USB devices, etc.).
4. Connect a to the on the and the other CAT5e/6 Cable RJ45 Port Docking Station
end to an RJ45 port on a .Network Device
5. Connect the on the to a Thunderbolt 3 Host Connector Docking Station
Thunderbolt 3 port on the .Host Laptop
Note: In Windows 10 or 8/8.1 you might see a pop-up message requesting permission
to allow the docking station to connect to your computer. If you see this pop-up
message, select from the list and click . If required, follow any Always Connect OK
other on-screen instructions to complete the installation.
Congure your display device
Use the Windows or macOS to adjust display settings for each connected monitor.
Supported Video Resolutions
Thunderbolt technology supports both video and data throughput. However, it
prioritizes video bandwidth to help ensure seamless display performance. The
performance of the remaining docking station functions depends entirely on the
display conguration you used.
1235
4
