Instruction Manual
Manual de instrucciones
STIH)
Read and follow all safety precautions in
Instruction Manual – improper use can cause
serious or fatal injury.
Lea y siga todas las precauciones de
seguridad dadas en el manual de
instrucciones – el uso incorrecto puede causar
lesiones graves o mortales.
Warning!
To reduce the risk of kickback injury use
STIHL reduced kickback bar and STIHL RM2
or RMC3 25 ) c ain de endi g on (.3 " h p n
sprocket or other available low kickback
components.
Advertencia!
Para reducir el riesgo de lesionarse como
resultado de un culatazo, utilice la barra de
contragolpe reducido y la cadena RM2 o
RM 3 325 p lg) de ST L, epe dien o de C (.u IH d n d
la rueda dentada usada y de otros
componentes reductores de contragolpe.
STIHL MS 280 C
1MS 280 C
English / USA
BA_SE_122_003_01_04.fmPrinted on chlorine-free paper.
Printing inks contain vegetable oils; paper can be recycled.
© ANDREAS STIHL AG & Co. KG, 2006
0458 150 8621 A. M0,5. J6. CP. Printed in USA
STIHl
Contents
Secondary Chain
Braking System ................................ 2
Guide to Using this Manual .............. 3
Some Important Safety Precautions
for Chain Saw Users ........................ 4
Safety Precautions and Working
Techniques ....................................... 6
Mounting the Bar and Chain
(Side chain tensioner) .................... 29
Mounting the Bar and Chain
(Quick Chain Tensioner) ................. 30
Tensioning the Saw Chain
(Side chain tensioner) .................... 33
Tensioning the Saw Chain
(Quick chain tensioner) .................. 34
Checking Chain Tension ................. 34
Fuel ................................................ 34
Fueling ............................................ 35
Chain Lubricant .............................. 37
Filling Chain Oil Tank ...................... 37
Checking Chain Lubrication ........... 38
Chain Brake ................................... 38
Winter Operation ............................ 40
Information Before You Start .......... 41
Starting / Stopping the Engine ........ 41
Operating Instructions .................... 44
Taking Care of Guide Bar ............... 45
Air Filter System ............................. 46
Cleaning the Air Filter ..................... 46
Motor Management ........................ 47
Adjusting the Carburetor ................ 47
Spark Arresting Screen
in Muffler ........................................ 49
Checking the Spark Plug ................ 50
Replacing Starter Rope
and Rewind Spring ......................... 51
Storing the Machine ....................... 53
Checking and Replacing
Chain Sprocket ............................... 54
Maintaining and Sharpening
Saw Chain ...................................... 55
Maintenance Chart ......................... 59
Main Parts of the Saw .................... 61
Specifications ................................. 63
Special Accessories ....................... 64
Ordering Spare Parts ..................... 64
Maintenance and Repairs .............. 65
STIHL Incorporated
Federal Emission Control
Warranty Statement ........................ 66
Trademarks .................................... 68
Allow only persons who understand this
Manual to operate your chainsaw.
To receive maximum performance and
satisfaction from your STIHL chainsaw,
it is important that you read and
understand
the maintenance and safety
p ec t s,r au ion
s art ng on ge , efore t i pa 4b
using your chainsaw.
Contact your STIHL dealer or the STIHL
distributor for your area if you do not
understand any of the instructions in this
Manual.
!Warning!
Because a chainsaw is a high-speed
wood-cutting tool, some special safety
precautions must be observed as with
any other power saw to reduce the risk
of personal injury.
Careless or improper use may cause
serious or even fatal injury.
STIHL's philosophy is to continually
improve all of its products. As a result,
engineering changes and improvements
are made from time-to-time. If the
operating characteristics or the
appearance of your chainsaw differs
from those described in this Manual,
please contact your STIHL dealer for
information and assistance.
2
English / USA
MS 280 C
This STIHL chainsaw is equipped with a
chain brake system that can be
activated in three different ways. As
before, the chain brake can be activated
by the inertia of the front hand guard in
certain kickback situations or manually
by pushing the front hand guard toward
the bar nose. In both of these cases the
brake, once activated, is designed to
bring the chain to a standstill within
fractions of a second. In addition, there
is a secondary system that is designed
to stop chain rotation within a second of
you letting go of the rear handle. The
locked chain is not released again until
you press down the throttle trigger
interlock lever to operate the throttle.
The chain brake can be activated in
three ways:
1By inertia in certain kickback
situations
2Manually via the front hand guard
3Manually by releasing the rear
handle
The activating mechanism for the
secondary chain braking system is
integrated in the throttle trigger interlock
lever (rear handle). One of the big
advantages of this system is that the
saw chain is automatically locked in
position for engine starts and when
carrying the running saw by the front
handle (with the rear handle released).
To reduce the risk of personal injury
or property damage during cutting,
observe the characteristics that
make this saw different from saws
not equipped with a secondary
chain braking system. Before
operating the chainsaw for the first
time, make sure you are familiar
with how the rear-handle activation
works. Pay special attention to the
chapters "Chain Brake" and
"Starting/Stopping the Engine".
Secondary Chain
Braking System
2
1
150BA000 KN
