1USG

English

BA_SE_025_002_01_06.fmPrinted on chlorine-free paper.

Printing inks contain vegetable oils; paper can be recycled.

0458 523 0121. M0,5. C4. T. Printed in Germany

STIHl

Contents

Guide to Using this Manual .............. 2

Safety Precautions ........................... 3

Applications ...................................... 4

Mounting the Tool ............................. 4

Selecting the Grinding Wheel ........... 6

Mounting the Grinding Wheel ........... 7

Test Run ........................................... 8

Dressing the Grinding Wheel ............ 8

Scales ............................................... 8

Setup for Sharpening Saw Chain ..... 9

Sharpening Procedure ................... 15

Lowering Depth Gauges ................. 17

Setup for Sharpening

Hedge Trimmer Blades ................... 19

Sharpening

Hedge Trimmer Blades ................... 24

Preparations for Sharpening

Circular Saw Blade ......................... 27

Sharpening Circular Saw Blade ...... 31

Maintenance Chart ......................... 32

Minimize Wear and

Avoid Damage ................................ 33

Main Parts of Sharpener ................. 34

Specifications ................................. 35

Special Accessories ....................... 35

Maintenance and Repairs ............... 35

Certificate of Conformity ................. 36

Quality Certification ........................ 36

Dear Customer,

Thank you for choosing a quality

engineered STIHL product.

This machine has been built using

modern production techniques and

comprehensive quality assurance.

Every effort has been made to ensure

your satisfaction and troublefree use

of the machine.

Please contact your dealer or our

sales company if you have any

queries concerning your machine.

Hans Peter Stihl

English

USG

Pictograms

All the pictograms attached to the

machine are shown and explained in

this manual.

The operating and handling instructions

are supported by illustrations.

Symbols in text

The individual steps or procedures

described in the manual may be marked

in different ways:

:Step or procedure without direct

reference to an illustration.

Description of step or procedure that

refers directly to the illustration and

contains item numbers that appear in

the illustration.

Example:

Loosen the screw (1)

Lever (2) ...

In addition to the operating instructions,

this manual may contain paragraphs

that require your special attention. Such

paragraphs are marked with the

symbols described below:

Warning where there is a risk of an

accident or personal injury or

serious damage to property.

Caution where there is a risk of

damaging the machine or individual

components.

Note or hint which is not essential

for using the machine, but may

improve the operator’s under-

standing of the situation and result

in better use of the machine.

Note or hint on correct procedure in

order to avoid damage to the

environment.

Equipment and features

This instruction manual refers to

several models with different

features. Components that are not

installed in all models and related

applications are marked with an

asterisk (*). Such components may

be available as special accessories

from your STIHL dealer.

Engineering improvements

STIHL’s philosophy is to continually

improve all of its products. As a result,

engineering changes and improvements

are made from time to time. If the

operating characteristics or the

appearance of your machine differ from

those described in this manual, please

contact your STIHL dealer for

assistance.

Therefore, we cannot be responsible for

changes, modifications or

improvements not covered in this

manual.

Guide to Using this Manual
