Sida 1/23
REV L DATE: 07/26/2023
USER MANUALS\20-17518_FUSION_USER MANUAL_GHSS(L)(H)HLB_HTD SHELVING-DECK_SELF-SVC_CASE
Note: See Next Page For Partial List Of
Models That This Manual Is Applicable To.
FUSION HEATED SHELVING, SELF-SERVICE 55 1/4”, 60” and 66 1/4” TALL MERCHANDISERS
Standard 3-Shelf Model GHSS460H (Shown
Stocked For Illustrative Purposes Only)
Standard 3-Shelf Model GHSS656HLB
(With Stainless Steel Front Bumper)
Standard 3-Shelf Model GHSS856HLB
(With Stainless Steel Front Bumper)
Standard 3-Shelf Model GHSS456HLB
Optional Controls Placement (Either Front or Rear)
With LEDs (Instead of Incandescent Lights)
SCC P/N
20-17518
USER
MANUAL
FUSION
CAREFULLY FOLLOW THESE INSTRUCTIONS
Structural Concepts Corp. ∙ 888 E. Porter Rd ∙ Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 ∙ www.structuralconcepts.com
2
TABLE OF CONTENTS
OVERVIEW / TYPE / COMPLIANCE / WARNINGS / PRECAUTIONS / WIRING / PLUGS .............…..
INSTALLATION: SKID REMOVAL / FRAME SUPPORT RAIL SHIMMING / LEVELER
ADJUSTMENTS ..………………………….…………………………………..…………………..…….
INSTALLATION, CONT’D: FIELD ACCESS WIRING CONNECTIONS/ SWITCHES /
THERMOMETERS …...………………………………………………………………………………….
INSTALLATION, CONT’D: IMPORTANT! HEATED SHELF “DANGER - HOT” LABEL PLACEMENT
REMOVING VERTICAL LOWER FRONT (OR REAR) PANELS …………………………………………..
START-UP, OPERATION & SHUTDOWN - MODEL GHSS460H & GHSS656HLB 3-SHELF UNITS
(FRONT ACCESS UNITS) / AUTHORIZED PERSONNEL ONLY! ..………………………………
START-UP & OPERATION - MODEL GHSS456HLB (REAR ACCESS UNIT) - AUTHORIZED
PERSONNEL ONLY! ..……………………………………………………………………………………
START-UP & OPERATION - MODEL GHSS460HLB 3-SHELF UNIT (FRONT ACCESS UNIT)
AUTHORIZED PERSONNEL ONLY! ..………………………………………………………………..
START-UP & OPERATION - MODEL GHSS660H 4-SHELF UNIT (FRONT ACCESS UNIT)
AUTHORIZED PERSONNEL ONLY! …………………………………………………………………
DOOR REMOVAL (OPTIONAL) / DECK, SHELVING, OVERHEAD DIFFERENTIATION ………...…...
INCANDESCENT LAMP FIXTURES / REPLACEMENT GUIDELINES ……….…………………………..
OPTIONAL LED LIGHTS / SWITCH / LED LIGHT FIXTURES / LED REMOVAL and
REPLACEMENT ………………………………………………………………………………………...
VAPOR THERMOMETER ……………………………………………………………………………………….
CLEANING SCHEDULE (DAILY / WEEKLY) - CASE EXTERIOR .………………………….……..……..
CLEANING SCHEDULE (DAILY / WEEKLY) - CASE INTERIOR ………………………………………....
CLEANING SCHEDULE (DAILY / WEEKLY) - CASE EXTERIOR & INTERIOR: STAINLESS STEEL
TROUBLESHOOTING ….…………………………………………………..………………...…………..……..
SERIAL LABEL & LOCATION / TECHNICAL INFORMATION / ADD’L INFORMATION ……..……….
PROGRAMMABLE CONTROLLER (SELECT, CLICK ON OR SCAN QR CODE FOR INFO)…………
TECHNICAL SERVICE CONTACT INFORMATION / WARRANTY INFORMATION ..…….………........
3-4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
This Manual Is Applicable To The Following Models*
GHSS452HLB / GHSS456HLB / GHSS460H / GHSS460HLB / GMSS467H / GMSS667H
GMSS867H / GHSS652HLB / GHSS656HLB / GHSS660H / GHSS856HLB
*This Manual May Be Applicable To Models Not Listed Above or Herein.
