FUSION SELF-SERVICE HIGH-VOLUME REFRIGERATED DISPLAY CASES (REMOTE UNITS)
REV G DATE: 07/31/2023
USER MANUALS\20-56435_FUSION_USER MANUAL_GHSSV(L)(H)RLB_REF_SELF-SVC_CASE
PLEASE NOTE THE FOLLOWING:
1. YOUR SPECIFIC MODEL NUMBER IS
LOCATED ON THE SERIAL LABEL.
HOWEVER, LABEL LOCATIONS MAY
VARY DEPENDING UPON MODEL.
2. CASES SHOWN IN THIS MANUAL
REFLECT FULL & OPEN END PANELS /
STRAIGHT OR ANGLED BASES.
3. NOT ALL MODELS COVERED BY THIS
OPERATING MANUAL ARE SHOWN ON
THIS COVER SHEET.
Model
GHSSV856RLB.6988D
Model
GHSSV852RLB
Model
GHSSV856RLB.6611B
Model
GHSSV356RLB
SCC P/N
20-56435
USER
MANUAL
FUSION
CAREFULLY FOLLOW THESE INSTRUCTIONS
Structural Concepts Corp. ∙ 888 E. Porter Rd ∙ Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 ∙ www.structuralconcepts.com
2
TABLE OF CONTENTS
TABLE OF CONTENTS ………………………………………………………………………………………..
OVERVIEW / TYPE / COMPLIANCE / WARNINGS / PRECAUTIONS / WIRING / PLUGS ..………….
INSTALLATION: REMOVAL FROM SKID, REMOVING VERTICAL LOWER FRONT PANELS ..…….
INSTALLATION, CONT’D: BOLTING AND CAULKING UNITS TOGETHER ...………………………….
INSTALLATION, CONT’D: GLASS SHELVING / ELEC LAYOUT / LED DRIVERS / OPTIONAL
BALLASTS ………………………………………………………………………………………………
INSTALLATION, CONT’D: ELECTRICAL LAYOUT / LED DRIVERS / OPTIONAL BALLASTS ...…….
INSTALLATION, CONT’D: FRAME SUPPORT RAILS / SEALING TO FLOOR …….…………………...
INSTALLATION, CONT’D: REFRIGERATION LINES / STUB-UPS / DRAINS / WIRING DIAGRAMS /
VENTILATION ……………………………………….………………………………………………….
INSTALLATION, CONT’D: DISPLAY CASE START-UP …………………………………………………...
MAINTENANCE FUNDAMENTALS: LED LIGHTS / BRACKETS / SHELVES .………….……………..
MAINTENANCE FUNDAMENTALS, CONT’D: DRAIN / TXV / REFRIGERATION LINES / SHUT-OFF
VALVE, TROUGH, SOLENOID, ETC….……………………………………………………………..
MAINTENANCE FUNDAMENTALS, CONT’D: REAR DOORS / PERFORATED ACRYLIC PLENUM .
GENERAL CLEANING (TO BE PERFORMED BY STORE PERSONNEL) ………………..……...…….
ENGINEERED (SYNTHETIC) QUARTZ CARE AND MAINTENANCE (TO BE PERFORMED BY
STORE PERSONNEL) ………………………………………………………………………………..
TROUBLESHOOTING (TO BE PERFORMED BY STORE PERSONNEL) ..………..…….……….…….
GENERAL CLEANING (TO BE PERFORMED BY TRAINED SERVICE PROVIDERS ONLY) ………..
TROUBLESHOOTING (TO BE PERFORMED BY TRAINED SERVICE PROVIDERS ONLY) ………..
SERIAL LABEL INFORMATION & LOCATION ..……………………………………...…....…………...…..
PROGRAMMABLE CONTROLLER (SELECT, CLICK ON OR SCAN QR CODE FOR
INFORMATION) ………………………………………………………………………………………..
TECHNICAL SERVICE CONTACT INFORMATION / WARRANTY INFORMATION ...………..…........
2
3-4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19-20
21
22
23
