Sida 1/26
FUSION SERVICE REFRIGERATED DISPLAY CASES
> REMOTE UNITS WITH VERTICAL FRONT HINGED GLASS
> LOCKING HARDWARE FOR FRONT GLASS
> VERTICAL & ANGLED REAR SLIDING DOORS
REV H DATE: 07/11/2023 USER MANUALS\20-57746_FUSION_USER MANUAL_GHSV(L)(H)RLB_REF_SVC_VERT’L FRT GLASS_CASE
Model GHSV852RLB
Model GHSV852RLB.6677B (Front Toe-Kick
Removed For Illustrative Purposes Only)
Model GHSV652RLB.6677C
Note: See Next Page For Models That
Are Represented By This Manual.
Model GHSV852RLB.6856D
(Front-Left Adjoinment /
Varying Size Front Glass)
Model GHSV556RLB
SCC P/N
20-57746
USER
MANUAL
FUSION
CAREFULLY FOLLOW THESE INSTRUCTIONS
Structural Concepts Corp. ∙ 888 E. Porter Rd ∙ Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 ∙ www.structuralconcepts.com
2
TABLE OF CONTENTS
TABLE OF CONTENTS ………………………………………………………………………………………..
OVERVIEW / TYPE / COMPLIANCE / WARNINGS / PRECAUTIONS / WIRING / PLUGS ..………….
INSTALLATION: REMOVAL FROM SKID, REMOVING LOWER FRONT PANELS ..……...…….…….
INSTALLATION, CONT’D: BOLTING AND SEALING UNITS TOGETHER ……………………………...
INSTALLATION, CONT’D: ELECTRICAL LAYOUT ………………………………………………………...
INSTALLATION, CONT’D: FRONT FAN ACCESS ………………………………………..………………..
INSTALLATION, CONT’D: FRAME SUPPORT RAILS / SEALING TO FLOOR ………………………...
INSTALLATION, CONT’D: FRONT GLASS ALIGNMENT & ADJUSTMENT - RAILS / LEVELERS ….
INSTALLATION, CONT’D: REFRIGERATION LINES / STUB-UPS / DRAINS / WIRING DIAGRAMS
INSTALLATION, CONT’D: SCALE STAND / OUTLETS / CAT-5 RECEPTACLE ……………………….
INSTALLATION, CONT’D: DISPLAY CASE START-UP .………………………………………………….
MAINTENANCE: LED LIGHT REMOVAL/REPLACEMENT, PLUG/CORD CONNECTION …………...
MAINTENANCE, CONT’D: DRAIN / TXV / REFRIGERATION LINES / SOLENOID / EVAP. FANS ….
MAINTENANCE FUNDAMENTALS - REAR SLIDING DOORS / THERMOMETER …………………....
MAINTENANCE FUNDAMENTALS - HINGED FRONT DOORS WITH LOCKING MECHANISM
(MODEL GHSV852RLB SHOWN, BUT IS APPLICABLE TO OTHER MODELS) ……………...
GENERAL CLEANING (TO BE PERFORMED BY STORE PERSONNEL) ………………..……...…….
TROUBLESHOOTING (TO BE PERFORMED BY STORE PERSONNEL) ..………..…….……….…….
GENERAL CLEANING (TO BE PERFORMED BY TRAINED SERVICE PROVIDERS ONLY) ………..
TROUBLESHOOTING (TO BE PERFORMED BY TRAINED SERVICE PROVIDERS ONLY) ………..
PREVENTIVE MAINTENANCE (TO BE PERFORMED BY TRAINED SERVICE PROVIDER)………..
SERIAL LABEL INFORMATION & LOCATION ..……………………………………...…....…………...…..
TECHNICAL SERVICE CONTACT INFORMATION / WARRANTY INFORMATION ...……….……......
2
3-4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21-23
24
25
26
Note: This Manual Is Applicable To Models GHSV452RLB / GHSV456RLB / GHSV556RLB /
GHSV652RLB.6677C / GHSV652RLB.6868C / GHSV852RLB / GHSV852RLB.6745D /
GHSV852RLB.6677B / GHSV852RLB.6856D / GHSV1052RLB.6745E GHSV1052RLB.6868E.
This Manual May Also Be Applicable On Other Models That Are Not Listed Herein.
