Before contacting, you must have the following:

Serial no., model no., store no., store address, details (photos, leak locations,

damage, store’s ambient conditions, etc.)

Support: structuralconcepts.com/support

Tech Service/Warranty: 1 (800) 433-9490, EXT. 1

Hours: Monday – Friday, 8am to 8pm EST (Closed holidays)

21-35378 OASIS REFRIGERATED/HEATED SELF-SERVICE-EN REV E DATE: 01/13/25

Oasis® User Manual

PART NUMBER: 21-35378

Please Note

Your specic model number is located on the

serial label (usually at the case rear). However,

label locations may vary depending on the

model – see page 20 for more details.

Models shown on this cover sheet do not

represent all models covered by this manual.

Models

B3924RH

B5024RH

B3924RH

Oasis® User Manual 2

Overview / Type / Compliance / Warnings / Precautions / Wiring / Plugs .............................................................................. 3-5

Installation: Case Removal From Skid .............................................................................................................................................6-7

Installation: Start Up ..............................................................................................................................................................................8

Placement of Case ................................................................................................................................................................................9

Product Placement .......................................................................................................................................................................... 10-11

Shelf and Deck Load Limits ..................................................................................................................................................................12

Lower Front Panel Removal .................................................................................................................................................................13

Rear Panel Removal ............................................................................................................................................................................ 14

Cleaning Schedule (To Be Performed by Store Personnel) ........................................................................................................... 15

Preventative Maintenance ........................................................................................................................................................... 16-20

Serial Label Information & Location ...................................................................................................................................................21

Programmable Controller Information .............................................................................................................................................22

Technical Service Contact Information / Warranty Information ..................................................................................................23

Table of Contents
