Sida 1/28
© 2021 by Snow Joe
®
, LLC
All rights reserved. Original instructions.
SAVE THESE INSTRUCTIONS
A Division of Snow Joe
®
, LLC
OPERATOR’S MANUAL
Model SPX-SRL9 Form No. SJ-SPX-SRL9-880E-MR1
R
PRESSURE WASHER SKY LANCE
9 FT UNIVERSAL | 120° GUTTER ADAPTER |30° ANGLED ADAPTER
1
IMPORTANT!
Safety Instructions
All Users Must Read These
Instructions Before Use
To reduce the risk of injury, the user must read and understand
this operator’s manual as well as the operator’s manual for
their pressure washer before using this product. Failure to
follow all warnings and precautions may result in death,
serious personal injury, or property damage.
1. A nozzle tip must be used with this pressure washer
sky lance. You may use the one included or any other
standard pressure washer tip.
2. Keep at least 50 feet away from power lines. Do not touch
or aim spray at electrical wiring of any kind.
3. Do not operate the sky lance, change nozzles or
accessories while spraying or while the wand is under
pressure. Turn o the pressure washer, shut o the water
supply, point the nozzle in a safe direction, and pull the
trigger to release water pressure before making any
changes.
4. Do not use the sky lance while on a ladder or scaolding.
5. When using the sky lance, make sure the high pressure
hose is located so that it will not be stepped on, tripped
over, or otherwise subjected to damage or stress. Keep
the hose clear of the working area.
6. Do not exceed the maximum pressure, volume, or
temperature listed in the product specications.
7. Do not remove or alter any warning labels included on the
sky lance.
8. Before operation, make sure the working area is clear of
obstructions or hazards.
9. Maintain proper balance and control of the sky lance at all
times.
10. To minimize the risk of kickback, grip the sky lance rmly
with both hands. A rm grip together with a sti arm will
help you maintain control of the sky lance if kickback
occurs.
Know Your Sky Lance
Read the owner’s manual and safety rules carefully before
operating the sky lance. Compare the illustration below to
the unit in order to familiarize yourself with the location of the
various controls and adjustments. Save this manual for future
reference.
1
2
3
4
5
6
7
8
9
10
11
8 12 13 8
13
15
16
17
13
18
1. Hose handle rest
2. Hose handle rest lock
button
3. Trigger gun
4. Trigger
5. Safety lock
6. Support bracket
7. Shoulder strap
8. Quick-Connect collar
9. 120° gutter adapter
10. Quick-Connect tip
11. 30° angled adapter
12. Hose adapter
13. Soft grip
14. 25° Quick-Connect
nozzle tip
15. Top extension lance
16. Middle extension lance
17. End extension lance
18. High-pressure hose
connection
14
2
Technical Data
Connections .......................... M22 15 mm Male Inlet
Quick-Connect Outlet
Threaded Accessory Port
Compatible Pressure ............. 1800 PSI – 4000 PSI
Max Water Flow ..................... 6 GPM
Max Water Temperature ........ 140°F (60°C)
Shoulder Strap Length .......... 6.2 ft (1.9 m)
Length ................................... Partially Connected: 6 ft. (1.8 m)
Fully Connected: 9 ft. (2.7 m)
Top Extension Lance ............. 35.4 in (90 cm)
Middle Extension Lance ........ 34.4 in (87.5 cm)
End Extension Lance ............. 38.4 in (97.5 cm)
Adapter .................................. M22 15 mm connection to
M22 14 mm connection
Net Weight ............................. 6.4 lbs (2.9 kg)
Unpacking
Carton Contents
• Trigger gun with top extension lance
• Shoulder strap
• 120° gutter adapter
• 30° angled adapter
• 25° Quick-Connect nozzle tip
• Middle extension lance
• End extension lance
• Hose adapter
• Manual + registration card
1. Carefully remove the sky lance and check to see that all of
the above items are supplied.
2. Inspect the product carefully to make sure no breakage or
damage occurred during shipping. If you nd damaged or
missing parts, DO NOT return the unit to the store. Please
call the Snow Joe
®
+ Sun Joe
®
customer service center at
1-866-SNOWJOE (1-866-766-9563).
NOTE: Do not discard the shipping carton and packaging
material until you are ready to use your new sky lance.
The packaging is made of recyclable materials. Properly
dispose of these materials in accordance with local
regulations.
IMPORTANT! The equipment and packaging material are not
toys. Do not let children play with plastic bags, foils, or small
parts. These items can be swallowed and pose a suocation
risk!
Assembly
Connect the Lance
The sky lance can be used when partially connected or fully
connected. Follow the instruction below to connect the
extension lances.
1. The sky lance can be partially connected using only the
top and the end extension lance. Insert the threaded end
of the end extension lance into the opening of the top
extension lance, and twist to secure (Fig. 1). A partially
connected sky lance will provide a total of 6 ft (1.8 m)
extension.
2. To fully connect the sky lance, insert the threaded end
of the middle extension lance into the opening of the top
extension lance and twist to secure (Fig. 2). Then connect
the end extension lance to the middle extension lance and
twist to secure (Fig. 3).
3. A fully connected sky lance will provide a total of 9 ft
(2.7 m) extension.
Fig. 1
Trigger gun
Top extension lance
End extension lance
Fig. 2
Top extension
lance
Middle extension
lance
Fig. 3
End extension lance Middle extension lance
