Information for Lot 9 of d )ErP (Eco esign
This addresses Ecodesign addendum European Union (EU) requirements for servers and storage
products addendum. All data and ratings within this are in reference only to the Supermicro product(s) in
th toe manual. The below information conforms Commission requirements laid down in Annex II of the
Regulation . 2019/424
3(1)(a): See Section 1.1 of the system manual for the product type.
3(1)(b): e See the title page and preface of th system manual for the trademark and
manufacturer’s address.
3(1)(c): See the title page of the system manual for product model number(s).
3(1)(d): See the serial number on the physical system to determine the year . of manufacture
3(1)(e-j ): PSU Efficiency V ) (F and Power Factor alue (Table rom 80 Plus report)
PSU Model #: PWS-1K02A 1R-
Watts: 1000W
PSU E fficiency
P Fower actor
% of R Lated oad
% % % %10 20 50 100
50 %
Single -Output (AC DC)
91.61%
94.73%
96.04%
94.03%
0.99
System (EUT) E P fficiency in I Sdle tate ower (Table)
Representative
Configurations
Measured Idle State
Power (W)
Calculated Idle Power
Allowance (W)
High-End Performance
Configuration
191.2
498.99
Typical Configuration
N/A
N/A
Low-End Performance
Configuration
128.2
312.91
System E(EUT) fficiency in A Sctive tate P ower (Table)
Representative
Configurations
Active tate S
E Sfficiency core
(Effserver)
Minimum A Sctive tate
Efficiency for 2-Socket
S erver
High-End Performance
Configuration
54.7
Typical Configuration
N/A
9.5
Low-End Performance
Configuration
32.5
3(1)( ): k is . The operating condition class A2
Dry bulb °Ctemp
Humidity range, non condensing-
Operati
ng
conditi
Allowab
le
range
Reco
m
mend
Allowable range
Recommended
range
Max
dew
point (°
C)
Maximu
m rate
of
change
A1
15- 32
18 27-
–
12 °C P Dew oint (DP)
and
8 % relative
humidity (RH) to
17 80°C DP and % RH
–
9 °C DP to
15 °C DP
and
60 %
17
5/20
A2
10 35-
18 27-
–
12 °C 8 % DP and RH
to
21 80 °C DP and %
Same as A1
21
5/20
A3
5-40
18 27-
–
12 °C 8 % DP and RH
to
24 85 °C DP and %
Same as A1
24
5/20
A4
5-45
18 27-
–
12 °C 8 % DP and RH
to
24 90 °C DP and %
Same as A1
24
5/20
3(1)( ): l The idle state power at the higher boundary temperature of the operating conditions
class is 225.62 W.
3(1)( ): m The active state efficiency and performance is 54.7.
3(1)(n): There are two methods by which a user can securely delete data from this system. The
user performing secure data deletion should be an IT professional.
The first is with a Unified Extensible Firmware Interface (UEFI) shell utility. This utility
works on X10/X11/H11/H12/M11 motherboard series with onboard SATA/NVMe devices.
Any user may access and download this utility through following link:
https://www.supermicro.com/about/policies/disclaimer.cfm?url=/wftp/utility/Lot9_Secure
_Data_Deletion_Utility/
Download the shell utility package and extract it to a USB flash drive, then plug the drive
into the server for which secure data deletion is necessary. Then turn the system on.
Navigate to the BIOS setup menu, then place the server system into the UEFI shell
environment. Follow the instructions in the README file to invoke the utility and
complete the deletion.
The second method is through the secure data deletion tool provided by the original
manufacturer of the hard drive. This should be used in a scenario where the shell utility
is not applicable. Each manufacturer should have the tool available on their website. If
needed, please look on the hard drive label for the name of the manufacturer and model
information.
3(1)( ): o List of recommended combinations of blade servers with chassis: N/A.
3(1)(p): List of all current SKUs within this product family: N/A.
3(3)(a): There is no use of cobalt in batteries in this product.
The indicative weight range of eodymium in the HDD is n 0.0 if manufactured by Western
Digital, and is between 5- 25 grams if manufactured by Seagate.
3(3)(b): Please see the disassembly instructions on the next page.
