AOC-EXPX9502FXSR

The is a 2-port 10 Gigabit Ethernet card AOC-EXPX9502FXSR

with dual XFP optical output connectors designed to meet

the throughput and latency requirements of bandwidth-

hungry applications, while offering a very low power

envelope for energy efficiency. This is the ideal choice for

multi-core processors and optimized for virtualization and at

the same time it satisfies the need for storage over Ethern

by supporting iSCSI acceleration and providing advanced

features for unified storage connectivity.

Key Features

PCI Express 2.0 (2.5GT/s)•

Low-prole•

Intel• ® I/O Acceleration Technology (I/OAT)

Load Balancing on Multiple CPUs•

VMDq for Virtualized Environment•

Low-latency interrupts•

10GBASE-SR on multi-mode ber•

Support up to 300m ber cable•

iSCSI Remote Boot•

Intel• ® PROSet Utility for Windows Device Manager

Specications

Intel® 82598EB dual-port 10 Gigabit Ethernet controller •

Two XFP connectors •

PCI-E p1-x8 •

Low-prole standard form factor •

Intel® I/OAT to improve CPU utilization •

MSI-X support to minimize the overhead of interrupts and allow load balancing of •

interrupt handling between dierent CPUs/cores

Low-latency interrupts •

Optimized queues: 32 Transmit (Tx) and 64 Receive (Rx) per port •

VMDq for virtualized environments •

Advanced packet ltering (per port)•

Direct Cache Access (DCA) •

PXE 2.0 enabled through boot read-only memory (ROM)•

iSCSI boot •

Supported ber cable length up to 300 meters •

Supported OS: Windows, Linux, VMWare •

Typical power consumption: 14W (1.17A @ 12V)•

Storage temperature: -40ºC to 70ºC (-40ºF to 158ºF)•

Storage humidity: 90% non-condensing relative humidity at 35ºC•

Physical dimensions: 16.74cm (6.59in) x 6.89cm (2.71in) (LxW)•

Height of end brackets: standard – 12cm (4.725in), low-prole – 7.92cm (3.12in)•

Compliance/

Environmental

RoHS Compliant 6/6, Pb Free •

RoHS

c o m p l i a n t

Supported Platforms Support motherboards with minimum PCI-E p1-x8 slot•

Support Servers with low-prole or full-height PCI-E expansion slot•

For the most current product information, visit:

ww w.supermicro.com

Produktspecifikationer

Varumärke:	Supermicro
Kategori:	Nätverkskort/adapter
Modell:	AOC-EXPX9502FXSR
Bredd:	68.90 mm
Djup:	167.40 mm
Gränssnitt:	Ethernet
Kompatibla operativsystem:	Windows, Linux, VMWare
Värdgränssnitt:	PCI Express
Maximal dataöverföringshastighet:	10240 Mbit/s
Typ av kabel:	Ethernet controller
Dataöverföringshastighet:	10 Gbit/s
Produktens färg:	Black, Green
Strömförbrukning (vanlig):	14 W
Temperaturintervall (förvaring):	-40 - 70 ° C
Fuktighet (förvaring):	0 - 90 %
Utgångsspänning:	12 V
Anslutningsteknologi:	Kabel
Intern:	Ja
Ingående ström:	1.17 A
Antal anslutningar:	2
Efterlever industristandard:	RoHS 6/6
