Sida 1/64
1.0a
®
SUPER
SC832/SC833 CHASSIS
USER'S GUIDE
MUTE RESET
!
2
2
2
2
1
R
1-2
S UPER SC832/SC833 Chassis User’s Guide
The information in this User’s Guide has been carefully reviewed and is believed to be
accurate. The vendor assumes no responsibility for any inaccuracies that may be
contained in this document, makes no commitment to update or to keep current the
information in this manual, or to notify any person or organization of the updates.
Please
Note: For the most up-to-date version of this manual, please see our
web site at www.supermicro.com.
SUPERMICRO COMPUTER reserves the right to make changes to the product described in
this manual at any time and without notice. This product, including software, if any, and
documentation may not, in whole or in part, be copied, photocopied, reproduced, translated
or reduced to any medium or machine without prior written consent.
IN NO EVENT WILL SUPERMICRO COMPUTER BE LIABLE FOR DIRECT, INDIRECT,
SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR
INABILITY TO USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, THE VENDOR SHALL NOT HAVE
LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED OR USED WITH THE
PRODUCT, INCLUDING THE COSTS OF REPAIRING, REPLACING, INTEGRATING,
INSTALLING OR RECOVERING SUCH HARDWARE, SOFTWARE, OR DATA.
Any disputes arising between manufacturer and customer shall be governed by the laws of
Santa Clara County in the State of California, USA. The State of California, County of
Santa Clara shall be the exclusive venue for the resolution of any such disputes.
Supermicro's total liability for all claims will not exceed the price paid for the hardware
product.
Unless you request and receive written permission from SUPER MICRO COMPUTER, you
may not copy any part of this document.
Information in this document is subject to change without notice. Other products and
companies referred to herein are trademarks or registered trademarks of their respective
companies or mark holders.
Copyright © 2004 by SUPER MICRO COMPUTER INC.
All rights reserved.
Printed in the United States of America
1-3
Chapter 1: Safety Information and Technical Specifications
Table of Contents
Chapter I: Safety Information and Technical Specifications .......... 1-4
1-1. Electrical Safety Guidelines ............................................................. 1-4
1-2. General Safety Guidelines ............................................................... 1-5
1-3. ESD Safety Guidelines ....................................................................... 1-6
1-4. Operation Safety Guidelines .......................................................... 1-6
1-5. Product Compliance Information ................................................. 1-8
1-6. Packing List and the SC832/SC833 Specifications ............... 1-9
Chapter 2: Chassis Description and Installation Procedures ........ 2-1
2-1. Chassis Description ........................................................................... 2-1
A. Contents of the Accessory Kit ............................................................... 2-1
B. Chassis Front View and the Front Control Panel ................................ 2-2
C. Chassis Rear View and the Back Panel .............................................. 2-4
2-2. Chassis Installation ........................................................................... 2-6
A. Important Safety Guidelines ..................................................................... 2-6
B. Tools Needed .............................................................................................. 2-6
C. Accessing the SCA Drive Tray and Installing a HDD .......................... 2-7
D. Removing the Top Cover of the Chassis ............................................... 2-8
E. Accessing the Front Chassis Fans ........................................................ 2-9
F. Accessing the Power Supply ................................................................ 2-10
G. Installing the Air Shrouds ....................................................................... 2-13
H. Installing the Motherboard ...................................................................... 2-15
I. Installing Chassis Rails ............................................................................ 2-17
J. Rack Installation ....................................................................................... 2-19
2-3
Chapter 2: Chassis Description and Installation Instructions
LED Button Descriptions
/('%XWWRQ &RORU &RQGLWLRQ 'HVFULSWLRQ
*UHHQ 2Q 6\VWHP2Q3RZHU
2II 6\VWHP2II
$PEHU %OLQN +''$FWLYLW\+''
2II 1R$FWLYLW\
*UHHQ 2Q /LQNHG
%OLQN /$1$FWLYLW\
/$1/$1
2II 'LVFRQQHFWHG
5HG 2Q 6\VWHP2YHUKHDW2YHUKHDW
2II 6\VWHP1RUPDO
5HG 2Q RUPRUH3:5PRGXOHVIDLOXUH6\VWHP$OHUW
3RZHU)DLOXUH 2II 6\VWHP1RUPDO
2-4
S UPER SC832/SC833 Chassis User’s Guide
C. Chassis Rear View and the Back Panel
*I/O Back Panel
Back Panel I/O Port Definitions
E. Keyboard & Mouse
SC832/SC833 Chassis Rear View
Back Panel Devices
A. Power Supply Modules (3) (*760W only)
B. Back Panel I/O Ports
C. Rear System Fan Slots(2)
F. USB Ports
G. COM/Video Ports
H. LAN1 & LAN2
I. Parallel Port
(*Note: The actual I/O Configuration of your system might be different
from the one shown above.)
A
B
C
D
D. Full size PCI Expansion Slots (6)
I
E F G H
2-5
Chapter 2: Chassis Description and Installation Instructions
Power Module LED Descriptions
&RORU&RQGLWLRQ 'HVFULSWLRQ
*UHHQ 3RZHU6XSSO\'&2Q
$PEHU 3RZHU6XSSO\6WDQGE\
3RZHU0RGXOH/('
2II 1R$&3RZHUWRWKHV\VWHP
2-6
S UPER SC832/SC833 Chassis User’s Guide
B. Tools needed
2-2 Chassis Installation
A. Important Safety Guidelines
Stop This product shall only be accessed, assembled and serviced
by technically qualified personnel or technicians.
To avoid personal injury and property damage, please read all the information
provided in Chapter 1, and carefully follow all the Safety Guidelines listed before
accessing or servicing the SC832/SC833 or its components. For your convenience,
some Safety Steps are also listed below:
Safety Steps
Before accessing the chassis:
1. Turn off all peripheral devices and turn off the power supply connected to the
SC832/SC833.
2. Unplug all power cords from the system or the wall outlets.
3. Disconnect all the cables and label the cables for easy identification.
4. Use a grounded wrist strap designed to prevent static discharge when han-
dling components.
Removing the chassis covers:
After completing the above steps, you can remove the chassis covers and install
components and devices into the chassis as described in this chapter.
1. Unlock and remove the screws and fasteners to remove the cover or components.
2. Save all the screws and fasteners for later use. (If necessary, label these screws
or fasteners for easy identification.)
3. Follow the instructions given in this chapter to remove the chassis covers.
1. Fillips Screw Driver
2. Antistatic Strap
2-7
Chapter 2: Chassis Description and Installation Instructions
C. Accessing the SCA Drive Tray and Installing a HDD
To install the SCA drive into the chassis, you need to first remove the SCA drive
tray from the chassis.
Procedures
1. Press the release tab located on the drive tray door to release the drive tray
from its locking position as shown below:
2. Pull the drive tray door upward and then pull the SCA drive tray out from the
chassis.
3. Mount a hard drive in the drive tray as shown below:
1
2
a
2b
3
a
3b
2-8
S UPER SC832/SC833 Chassis User’s Guide
D. Removing the Top Cover of the SC832/SC833 Chassis
Before installing any components, replacing chassis fans or accessing the
motherboard, you will first need to remove the top cover.
Procedures
1. Press the release tabs to release the cover from its locking position.
2. Once the top cover is released from its locking position, push the cover toward
the rear side and slide it out from the chassis.
2
1
2-9
Chapter 2: Chassis Description and Installation Instructions
E. Accessing the Front Chassis Fans
Procedures
1. Press the release tab located on the left side of the front chassis fan (when
facing the front side of the fan) to release the chassis fan from its locking
position as shown in the picture below:
2. Once you've loosened the front chassis fan, you can pull the fan out.
1
2
2-10
S UPER SC832/SC833 Chassis User’s Guide
F-1. Accessing the 760W Power Supply (*For Triple Redundant
Power Supply-3xPWS-0050M)
Procedures
1. Locate the release tab on the left side of the power supply.
2. Push the release tab to the right to release the power supply from its locking
position as shown below:
3. Once the power supply module is released from its locking position, remove
it from the chassis.
Warning: Do not open the casing of a power supply.
Power supplies can only be accessed and serviced by a
qualified technician from the manufacturer.
!
(*Caution: Unplug the Power Cord before removing the Power
Supply!!)
1
2
3
2-11
Chapter 2: Chassis Description and Installation Instructions
F-2. Accessing the 550W-Power Supply (*For Single PWS-0047)
Procedures
1. Unscrew the screws to remove the metal plate.
2. Remove the four screws from the power supply.
3. Pull the power supply out from its housing as shown in the picture:
(PWS-0047)
(*Caution: Unplug the Power Cord before removing the Power
Supply!!)
2
1
3
2-12
S UPER SC832/SC833 Chassis User’s Guide
!
Warning: For proper cooling, please be sure to install the air shroud
and all the chassis covers before you operate the system.
G. Installing the Air Shrouds
AAa
The SC832/833 chassis and the locations of the Large and Small Air
Shrouds
A
B
C
D
E
E
A. Large Air Shroud
B. Small Air Shroud
C. Rear Fans
D. Power Supply
E. Front Fan#1
The Back View of the
Front Fan#1
2-13
Chapter 2: Chassis Description and Installation Instructions
Procedures
2. Locate the six tabs (labelled J, K, L, M, N, and O) on the Small Air Shroud
and the six corresponding holes (marked as j, k, l, m, n, and o) on the
chassis as shown in the pictures below.
I. Installing the Small Air Shroud
3.Align each tab on the Small Air Shroud with its corresponding hole on the
chassis, and insert the tab into its corresponding hole. Make sure that the
Small Air Shroud is securely installed in the proper place as shown on the
picture.
J
K
LM
N
O
j
k
l
m
n
o
1. Identify the location of the small shroud between the rear side of Front
Fan#1 (labelled "E" on the previous page) and the Power Supply (labelled
"D"). The Small Air Shroud is to be installed on the back wall of the Front
Fan1(E) and in front of the Power Supply (D).
J
K
N
O
2-14
S UPER SC832/SC833 Chassis User’s Guide
II. Installing the Large Air Shroud
Procedures
1. Remove all the rear fans from the chassis if you have not done so. You can
remove a rear fan from the chassis by pressing the release tab on the upper
right corner of the fan and pulling the fan out of the chassis.
2. Align the Large Air Shroud against the rear fan stem (labelled 2) and gently
push the air shroud into the chassis.
3. Slide the rear fans into the fan slots. Make sure that the fans are securely
fastened on the chassis.
2
2-15
Chapter 2: Chassis Description and Installation Instructions
H. Installing the Motherboard
Be sue to disconnect the power supply before accessing or installing the mother-
board into the chassis. However, you will need to, first, identify the CPU locations,
and then, install the correct type of standoffs under the CPUs before installing the
motherboard into the chassis. (Refer to Chapter 1 for Safety Guidelines.)
Procedures
1. Lay the chassis on a flat surface. Locate the CPU mounting holes on the
chassis and install CPU standoffs on the chassis.
(**Note: the motherboard shown above is for reference only!! The motherboard
is not included in the SC832/SC833 shipping package.)
1
2-16
S UPER SC832/SC833 Chassis User’s Guide
3. Secure the motherboard to the chassis with Type A(6-32) screws as shown
above. (*Please refer to Page 2-1 MB kit for the Type A screw.)
4. Secure the CPU heatsink mechanism to the motherboard.
2. Install standoffs to all the remaining mounting holes on the motherboard.
Then, lay the motherboard on the standoffs.
Warning: For proper cooling, please make sure that all the
chassis covers are installed before you operate the system. Out
of warranty damage can occur if this rule is not strictly followed.
!
2
A
3
4
(**Note: the CPU shown above is for reference only!! The motherboard is not
included in the SC832/SC833 shipping package.)
2-17
Chapter 2: Chassis Description and Installation Instructions
Press the Locking Tab
I. Installing Chassis Rails
Please make sure that the chassis covers and chassis rails are installed on the
chassis before you install the chassis into the rack.
Procedures to Install Chassis Rails
2. Press the locking tab to release the inner rail from its locking position and
pull out the inner rail from the rail assembly. (*The inner rails are to be attached
to the chassis and the outer rails are to be installed in the rack.)
Outer rail (to be installed in the
rack)
Pull out the Inner
rail (to be
attached on the
chassis)
1. Included in the shipping package are a pair of rail assemblies. In each rail
assembly, locate the inner rail and the outer rail.
Before installing the Chassis rails:
1. Enclose the chassis with chassis covers.
2. Unplug the AC power cord(s).
3. Remove all external devices and connectors.
To avoid personal injury and property damage, please carefully
follow all the safety steps listed below:
2-18
S UPER SC832/SC833 Chassis User’s Guide
3. Locate the five rail buttons on each side of the chassis and locate the five
corresponding holes on each of the inner rail.
4. Align the larger end of each hole against its corresponding button. Once all
aligned, push the holes toward their corresponding buttons and the rail is placed
on the chassis.
5. Once the rail is placed on the chassis, pull the rail forward until the rail
buttons lock in the small ends of the corresponding holes.
6. Secure the rail to the chassis with a Type G screw (Refer to Page 2-1 for the
Type G screw.) Repeat the above steps to install other rail on the chassis.
3
(*Please note that one end of the hole is larger than the other end of the hole.)
4
5
6
G
Produktspecifikationer
| Varumärke: | Supermicro |
| Kategori: | Inte kategoriserad |
| Modell: | SC833T-R760 |
Behöver du hjälp?
Om du behöver hjälp med Supermicro SC833T-R760 ställ en fråga nedan och andra användare kommer att svara dig
Inte kategoriserad Supermicro Manualer
1 April 2025
1 April 2025
31 Januari 2025
31 Januari 2025
31 Januari 2025
31 Januari 2025
9 Januari 2025
4 Januari 2025
29 December 2024
29 December 2024
Inte kategoriserad Manualer
- AJA
- Handicare
- AudioControl
- Zipper
- Squarp Instruments
- Masterbuilt
- KM-fit
- James
- Park Tool
- EXO
- Ninja
- Xiaomi
- Jonard Tools
- Lifan
- Eura
Nyaste Inte kategoriserad Manualer
9 April 2025
9 April 2025
9 April 2025
9 April 2025
9 April 2025
9 April 2025
9 April 2025
9 April 2025
9 April 2025
9 April 2025
