SUPER STORAGE SYSTEM

2028R-E1CR24L

USER’S MANUAL

1.0a

iii

Preface

About This Manual

This manual is written for professional system integrators and PC technicians. It

provides information for the installation and use of the 2028R-E1CR24L. Installation

and maintenance should be performed by experienced technicians only.

The 2028R-E1CR24L is a high-end storage system based on the SC216BE1C-

R920LPB 2U rackmountable chassis and the X10DRH-iT dual processor

serverboard.

Manual Organization

Chapter 1: Introduction

The rst chapter provides a checklist of the main components included with the

system and describes the main features of the X10DRH-iT serverboard and the

SC216BE1C-R920LPB chassis.

Chapter 2: Server Installation

This chapter describes the steps necessary to install the 2028R-E1CR24L into a

rack and check out the server conguration prior to powering up the system. If your

server was ordered without processor and memory components, this chapter will

refer you to the appropriate sections of the manual for their installation.

Chapter 3: System Interface

Refer here for details on the system interface, which includes the functions and

information provided by the control panel on the chassis as well as other LEDs

located throughout the system.

Chapter 4: Standardized Safety Warnings

You should thoroughly familiarize yourself with this chapter for a general overview

of safety precautions that should be followed when installing and servicing the

2028R-E1CR24L.

The information in this User’s Manual has been carefully reviewed and is believed to be accurate.

The vendor assumes no responsibility for any inaccuracies that may be contained in this document,

makes no commitment to update or to keep current the information in this manual, or to notify any

person or organization of the updates. Please Note: For the most up-to-date version of this

manual, please see our web site at www.supermicro.com.

Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product

described in this manual at any time and without notice. This product, including software and docu-

mentation, is the property of Supermicro and/or its licensors, and is supplied only under a license.

Any use or reproduction of this product is not allowed, except as expressly permitted by the terms

of said license.

IN NO EVENT WILL SUPERMICRO BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL,

SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY TO

USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF

SUCH DAMAGES. IN PARTICULAR, SUPERMICRO SHALL NOT HAVE LIABILITY FOR ANY

HARDWARE, SOFTWARE, OR DATA STORED OR USED WITH THE PRODUCT, INCLUDING THE

COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING OR RECOVERING SUCH

HARDWARE, SOFTWARE, OR DATA.

Any disputes arising between manufacturer and customer shall be governed by the laws of Santa

Clara County in the State of California, USA. The State of California, County of Santa Clara shall

be the exclusive venue for the resolution of any such disputes. Super Micro's total liability for all

claims will not exceed the price paid for the hardware product.

FCC Statement: This equipment has been tested and found to comply with the limits for a Class A

digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is operated in a commercial environ-

ment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed

and used in accordance with the manufacturer’s instruction manual, may cause harmful interference

with radio communications. Operation of this equipment in a residential area is likely to cause harmful

interference, in which case you will be required to correct the interference at your own expense.

California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate warn-

ing applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate

Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”

WARNING: Handling of lead solder materials used in this

product may expose you to lead, a chemical known to the

State of California to cause birth defects and other repro-

ductive harm.

Manual Revision 1.0a

Release Date: May 13, 2016

Unless you request and receive written permission from Super Micro Computer, Inc., you may not

copy any part of this document.

Information in this document is subject to change without notice. Other products and companies

referred to herein are trademarks or registered trademarks of their respective companies or mark

holders.

Printed in the United States of America

SUPERSTORAGESYSTEM 2028R-E1CR24L User's Manual

Notes

Chapter 5: Advanced Serverboard Setup

Chapter 5 provides detailed information on the X10DRH-iT serverboard, including

the locations and functions of connections, headers and jumpers. Refer to this

chapter when adding or removing processors or main memory and when recong-

uring the serverboard.

Chapter 6: Advanced Chassis Setup

Refer to Chapter 6 for detailed information on the SC216BE1C-R920LPB chassis.

You should follow the procedures given in this chapter when installing, removing

or reconguring hard drives and when replacing system power supply units and

cooling fans.

Chapter 7: BIOS

The BIOS chapter includes an introduction to BIOS and provides detailed informa-

tion on running the CMOS Setup Utility.

Appendix A: BIOS Error Beep Codes

Appendix B: System Specications

Preface

Produktspecifikationer

Varumärke:	Supermicro
Kategori:	Inte kategoriserad
Modell:	SuperServer 2028R-E1CR24L
Vikt:	27700 g
Bredd:	437 mm
Djup:	630 mm
Höjd:	89 mm
Strömförsörjning:	920 W
LED-indikatorer:	Ja
Processorfamilj:	Intel
Minneskapacitet:	72 bit
Maximalt internminne:	2000 GB
Minnesspänning:	1.2 V
Kompatibla processorer:	Intel® Xeon®
Antal processorer som stöds:	2
Intel® Xeon-serien:	E5-2600
Antal lagringsenheter som stöds:	24
Minnestyper som stöds:	DDR4-SDRAM
BIOS-typ:	AMI
ACPI-version:	2.0
Maximal cache:	55 MB
Produktens färg:	Black, Grey
Typ av ethernet-gränssnitt:	Fast Ethernet, Gigabit Ethernet
Datahastighet för Ethernet-LAN:	10,100,1000 Mbit/s
Antal LAN (RJ-45) anslutningar:	2
Temperatur vid drift:	10 - 35 ° C
Temperaturintervall (förvaring):	-40 - 70 ° C
Intervall för relativ operativ luftfuktighet:	8 - 90 %
Fuktighet (förvaring):	5 - 95 %
processorsockel:	LGA 2011 (Socket R)
Hållbarhetscertifiering:	RoHS
AC-inspänning:	100 - 240 V
Fläktdiameter:	80 mm
Nätverksansluten (Ethernet):	Ja
Växelström Frekvens:	50 - 60 hz
BIOS-funktioner:	APM 1.2, PCI 2.2, Plug & Play, SMBIOS 2.3, UEFI
På / av-knapp:	Ja
Antal USB 2.0 anslutningar:	2
RAID-nivåer:	0, 1,5, 10
Antal USB 3.2 Gen 1 (3.1 Gen 1) typ A-portar:	2
BIOS minnesstorlek:	16 mbit
LAN-styrenhet:	Intel® X540
Moderkortets chipset:	Intel® C612
Antal fläktar:	3 fläkt/-ar
Kvalitet på VGA (D-Sub) porten:	1
Systembuss, hastighet:	9.6 GT/s
Ombord grafikkort modell:	Aspeed AST2400
Storlekar som stöds på lagringsenhet:	2.5 "
Koppar Ethernet-kablar teknik:	10GBASE-T, 100BASE-TX, 1000BASE-T
Lagringsenhetsgränssnitt som stöds:	Serial Attached SCSI (SAS)-3, Serial ATA III
ECC:	Ja
Chassityp:	Rack (2U)
Antalet DIMM-platser:	16
Hårddisk hot swap:	Ja
Minnets formfaktor:	288-pin DIMM
PCI Express x16 platser:	1
PCI Express x8 kortplatser:	6
Maximalt RDIMM minne:	512 GB
IPMI LAN (RJ-45)-port:	Ja
Likspänning ut (+12 V):	75 A
Likspänning ut (+5 V):	4 A
