Sida 1/32

www.sven.fi

USER MANUAL

2.1 Multimedia

Speaker System

MS-304

MS-307

ENG

2.1 Multimedia

Speaker System

Congratulations on your purchase of the Sven speaker system!

TRADEMARKS

All trademarks are the property of their legal holders.

NOTICE OF RESPONSIBILITY RESTRICTION

Despite the exerted eorts to make this Manual more exact, some discrepancies may occur.

Theinformation in this Manual is given on «as is» terms. The author and the publisher do notbear

any liability to a person or an organization for loss or damage which has arisen from the infor-

mation contained in this Manual.

CONTENTS

ENG ............................................................................................................................................... 2

1. BUYER RECOMMENDATIONS .................................................................................................. 2

2. PACKAGE CONTENTS ............................................................................................................... 3

3. SAFETY PRECAUTIONS ............................................................................................................. 3

4. TECHNICAL DESCRIPTION ....................................................................................................... 3

5. PREPARATION AND OPERATION ............................................................................................ 6

6. OPERATION MODES ................................................................................................................. 7

7. TROUBLESHOOTING .............................................................................................................. 10

8. TECHNICAL SPECIFICATIONS ................................................................................................ 10

RUS .............................................................................................................................................. 11

UKR ............................................................................................................................................. 20

1. BUYER RECOMMENDATIONS

• Unpack the device carefully. Make sure there are no accessories left in the box. Check up

thedevice for damage; if the product was damaged during transportation, address the rm

which carried out the delivery; if the product functions incorrectly, address the dealer at once.

• Check up the package contents and availability of the warranty card. Make sure the war-

ranty card has a shop stamp, a legible signature or the seller’s stamp and purchase date,

andthegoods number corresponds to that in the warranty card. Remember: in case of warran-

ty card loss ordiscrepancy of numbers you forfeit the right for warranty repairs.

• Do not switch on the speaker system immediately after you bring it into a room from environ-

ment with negative temperature! After unpacking, the speaker system should be kept incondi-

tions ofroom temperature for at least 4 hours.

• Before installing and using the speaker system, read this Manual carefully and keep it forfu-

ture reference.

• Shipping and transportation equipment is permitted only in the original container.

• Does not require special conditions for realization.

• Dispose of in accordance with regulations for the disposal of household and computer equip-

ment.

• The date of manufacture of the product is indicated on the box.

Technical support is on www.sven..

ENG

MS-304

MS-307

User Manual

2. PACKAGE CONTENTS

• Subwoofer — 1 pc.

• Satellites — 2 pcs.

• Remote control (RC) — 1 pc.

• AAA type batteries — 2 pcs.

• Signal cable — 1 pc.

• Antenna wire — 1 pc.

• User manual — 1 pc.

• Warranty card — 1 pc.

3. SAFETY PRECAUTIONS

Caution! High voltage inside! To avoid the risk of electric shock

donot open or touch elements inside.

• To avoid electric shock, do not open the MSS and do not perform repairs by yourself. Service

and repairs should be performed only by qualied specialists in an authorized service center.

Thelist of authorized service centers is available on www.sven..

• Do not allow the circuit of wires (including the grounded ones) between the speakers,

onthepower amplier or the ground, for it causes damage to the power amplier output stage.

• Do not touch the MSS power cord plug pins for 2 seconds after unplugging it from the mains.

• Do not put foreign objects inside the holes of the MSS.

• Protect the MSS from high humidity, water and dust.

• Protect the MSS from heating: do not place it closer than 1 m from a heat source. Do notex-

pose it to direct sunlight.

• Do not place any open ame sources on or close to MSS.

• Do not place the MSS in poorly ventilated areas. Leave an air gap of 10 cm or more. Whenop-

erating the MSS, do not put any devices on it, do not cover it with cloth or other objects prevent-

ing it from cooling.

• Do not use any chemical agents for cleaning. Clean it with dry soft cloth only.

4. TECHNICAL DESCRIPTION

MS-304/MS-307 2.1 Multimedia Speaker System (MSS) is designed to play music and sound

games, movies, etc. The MSS has a built-in power amplier and audio cables tnabling it to con-

nect to virtual to any audio source (CD/DVD-player, TV, PC, etc.) without using an additional

power amplier. The MSS has a built-in FM radio, Bluetooth module and audio les player.

Remote control is included.

Features

• Speaker system is compatible with PCs, DVD/Media-players, mobile devices and other sound

sources.

• Wireless signal transmission via Bluetooth module.

• Built-in audio les player from external storage devices.

• Built-in FM radio.

• Alphanumeric LED display.

• USB ash port and SD card slot.

• Remote control.

• MUTE and ST-BY modes.

• Wooden (MDF) cabinets of the subwoofer and satellites.

Produktspecifikationer

Varumärke:	Sven
Kategori:	högtalare
Modell:	MS-304
Vikt:	3300 g
Frekvensband:	FM
Volymkontroll:	Rotations-
Rekommenderad användning:	Universal
Ljudutgångskanaler:	2.1 kanaler
Fjärrstyrd:	Ja
Kompatibla produkter:	PCs, DVD/Media-players, mobile devices and other sound sources
Bluetooth-räckvidd:	10 m
Subwooferns mått (BxDxH):	159 x 272 x 245 mm
Fjärrkontroll ingår:	Ja
Typ av satellithögtalare:	2-vägs
Förstärkningsenhet ingår:	Ja
Produktens färg:	Svart
bruksanvisning:	Ja
Typ av fjärrkontroll:	IR
Uteffekt (RMS):	40 W
AC-inspänning:	220 V
Material, hölje:	MDF
Subwoofer RMS-effekt:	20 W
Subwooferns frekvensomfång:	40 - 150 hz
Anslutningsteknologi:	Kabel & Trådlös
Växelström Frekvens:	50 hz
På / av-knapp:	Ja
Strömkälla:	AC
Antal USB 2.0 anslutningar:	1
Antal satellithögtalare:	2
Garantisedel:	Ja
Bluetooth:	Ja
Externa anslutningar:	SD: slot for SD/MMC cards; FM ANT: radio antenna input jack; PC: jack to connect PC, mobile devices, and other audio sources
Förpackningarnas innehåll:	Subwoofer — 1 pc; Satellites — 2 pcs; Remote control (RC) — 1 pc; AAA type batteries — 2 pcs; Signal cable — 1 pc; Antenna wire — 1 pc; User manual — 1 pc;\n Warranty card — 1 pc
Basnivåkontroll:	Ja
Satellithögtalarens RMS-effekt:	20 W
Satellithögtalarens mått (BxDxH):	104 x 171 x 108 mm
Förstärkningsenhetens formfaktor:	Inbyggd
Frekvensområde för satellithögtalare:	150 - 20000 hz
