Sida 1/16

Portable Speaker System with

Bluetooth and FM-radio

PS-500

PS-550

USER MANUAL

Portable Speaker System with

Bluetooth and FM-radio

ENG

Congratulations on your purchase of the SVEN speaker system!

COnTenTs

enG 2 ...............................................................................................................................................

rUs 6 ................................................................................................................................................

UKr.............................................................................................................................................. 11

BUYer reCOMMenDaTIOns

• Unpack the device carefully. Make sure there are no accessories left in the box. Check up the

device for damage; if the product was damaged during transportation, address the firm which

carried out the delivery; if the product functions incorrectly, address the dealer at once.

• Shipping and transportation equipment is permitted only in the original container.

• Does not require special conditions for realization.

• Dispose of in accordance with regulations for the disposal of household and computer equipment.

aPPlICaTIOn

SVEN PS-500, PS-550 portable multimedia speaker system with Bluetooth and FM-radio is

designed for operation with PC, notebooks and other mobile devices by means of data transfer

via Bluetooth protocol. It can be also used in internet telephony, during video conferences, in

multimedia applications, in interactive games, for speech recognition and foreign language

teaching. Microphone input with echo function, FM-tuner and the player with USB-flash and micro

SD-cards are included.

PaCKaGe COnTenTs

• Speaker system – 1 pc

• 3.5 mm mini-jack to 3.5 mm mini-jack signal cable – 1 pc

• USB to micro USB power cable – 1 pc

• Carrying strap – 1 pc

• User Manual – 1 pc

• Warranty card – 1 pc

sPeCIal FeaTUres

• Bluetooth wireless signal transmission

• Effective multi-colored lighting

• Wireless connection of two speakers to one source*

• Track switching control possibility

• Wired/wireless audio signal transmission

• Built-in player for audio files from USB-flash and micro SD card

• Built-in equalizer

• Microphone input with echo function

• Built-in FM tuner

• LED display

*Only for models with date of production from 04.2021.

ENG

User Manual PS-500

PS-550

Speaker system description

a MODE: switching modes button: Bluetooth/Radio / Player/LINE IN (short press);

ON/OFF the service signals (long pressing in Bluetooth mode)

b EQ: EQ mode switch button

c LIGHT: switching backlight modes (short press);

Turning on / off the backlight (long press)

d DEL: FM station deletion (long press in Radio mode)

Connecting an additional speaker (only in Bluetooth mode)

e CH/ : button for switching between stations or frequency (in Radio mode);

repeat mode selection button (in the Player mode): ONE – repeats the current track; RAND – play

tracks in the random order; ALL – plays all tracks in the sequential order

f FM-/ : next track (short pressing in Player and Bluetooth mode); Navigation on the track

(long pressing in Player mode); Next track/station (in Radio mode)

g AUTO SCAN/ : Play/Pause button (in Player and Bluetooth mode); Start/Stop auto scan (long

pressing in Radio mode); Mute (short pressing in Radio mode)

h FM+/ : next track (short pressing in Player and Bluetooth mode); Navigation on the track

(long pressing in Player mode); Next track/station (in Radio mode)

i DC 5V IN: micro USB jack for charger connecting, the USB port of laptop / PC

j Indicator

k ON/OFF: POWER button

l Display

m TF CARD: micro SD card slot

n USB: USB-flash card slot

o AUX IN: 3.5 mm mini-jack for audio

signal connecting (phone, MP3 player, etc.)

p MIC: 6.3 mm jack microphone jack

q MIC VOL +/-: microphone volume

control knob

r ECHO +/-: microphone echo

adjustment knob

s VOLUME: volume control knob

Fig.1.

CONNECTION AND OPERATION

Attention! The built-in battery must be

charged completely prior to the application.

Speaker system battery charging

• Connect speaker system to a USB port of

PC or USB charger using micro USB to USB

cable (included). During battery charging the

indicator j is red. Indicator j goes out when

the battery is charged.

• The battery is used in the speaker system

as an integral part of the device, therefore do

not try to extract or replace it, because this can

result in the warranty cancellation or the device

damage.
