SE-103 flush-mount single double-pole two-way switch is designed for electrical circuits

switching.

FEATURES

• Non-ammable PC plastic casefl

• Zinc-galvanized steel core

• Copper terminals with silver coating

• Wide functional possibilities (double-pole two-way switch, intermediate switch, etc.)

• Undyed plastic color

SAFE OPERATION RULES

•

Switches should be installed and connected by qualied specialists only.fi

•

Switches should be connected according to the connection diagram given on the item

backside.

•

Avoid the item overload for its damage. The peak acceptable current value of the load

is indicated on its backside.

•

Avoid ingress of foreign objects inside the item case.

USER’S MANUAL

Dimensions, mm

Peak current, А

Peak voltage, V

Color

85 × 81

10

250

white, ivory

Single Double-Pole Switch

TECHNICAL SPECIFICATIONS

Notes:

• Technical specications given in this table are supplemental information and fi

cannot give occasion to claims.

• Technical specifications are subject to change without notice due to the im-

provement of SVEN production.

SE-103
