COPYRIGHT
© 2014. SVEN
PTE. LTD
. Version 1.0 (V 1.0).
This Manual and information contained in it are copyrighted. All rights reserved.
TRADEMARKS
All trademarks are the property of their legal holders
.
NOTICE OF RESPONSIBILITY RESTRICTION
Despite the exerted eorts to make this Manual more exact, some discrepancies may ff
occur. The information of this Manual is given on “as is” terms. The author and the pub-
lisher do not bear any liability to a person or an organization for loss or damages, which
have arisen from the information contained in the given Manual
.
PURPOSE
Flush-mount one-way illuminated dimmers of SE-60038C type (white) and SE-60038C-С
type (cream) are designed for electrical circuits switching.
FEATURES
• Non-ammable ABS plastic casefl
• Smooth illumination level adjustment
• Triac-based electronic circuit
• Knob on/o switchff
• Illumination level memorizing feature
• Knob backlight for convenient use in dark environment
SAFE OPERATION RULES
•
Items should be installed and connected by qualied specialists only.fi
•
Items should be connected according to the connection diagram given on the item
backside.
•
Avoid the item overload for its damage. The peak acceptable current value of the load
is indicated on its backside.
•
Avoid ingress of foreign objects inside the item case.
Note. The dimmer can be used with halogen or incandescent bulbs only. Using the
dimmer with uorescent and energy saving bulbs is prohibited!fl
USER’S MANUAL
Dimensions, mm
Peak current, А
Peak voltage, V
82 × 82
2
250
One-way dimmer illuminated
TECHNICAL SPECIFICATIONS
Notes:
• Technical specications given in this table are supplemental information and fi
cannot give occasion to claims.
• Technical specifications are subject to change without notice due to the im-
provement of SVEN production.
SE-60038C
