Escape
Tech Handbook
Swift Group
Dunswell Road
Cottingham
East Yorkshire HU16 4JX
Tel 01482 875740
Fax 01482 840082
email enquiry@swiftgroup.co.uk
For more information visit
www.swiftgroup.co.uk
Issued July 2012
1400754
1
Contents
Specifications ............................................................................. 2
Capacities ................................................................................... 6
Towing Capabilities .................................................................... 7
Jacking ....................................................................................... 8
Wiring Diagrams ......................................................................... 9
Bulb Chart ................................................................................. 15
Bulb Replacement ...................................................................... 16
2 3
Specifications
NOTE: 1. The Maximum User Payload includes:
a) the conventional load (this is the allowance for
passengers)
b) essential habitation equipment (items and
fluids required for safe and proper functioning of
habitation equipment)
c) optional equipment (items available from
the manufacturer over and above the standard
specification)
d) personal effects (those items not covered by
the above)
2. The Mass in Running Order is the mass of the
unladen vehicle including a 75kg allowance for the
driver plus engine coolants and 90% of the fuel tank,
water tank and gas capacity.
3. PLEASE TAKE CARE TO ENSURE THAT YOU HAVE
ALLOWED FOR THE MASSES OF ALL ITEMS YOU
INTEND TO CARRY IN THE MOTOR CARAVAN,
e.g. passengers, optional equipment, essential
habitation equipment and personal effects, such
as clothing, food, pets, bicycles, sailboards, sports
equipment etc.
4. WARNING - UNDER NO CIRCUMSTANCES
SHOULD THE MAXIMUM TECHNICAL PERMISSIBLE
LADEN MASS OF THIS MOTOR CARAVAN BE
EXCEEDED.
* For optional roof ladder (add 200mm).
Model
Escape 624 Standard Escape 624 Optional Escape 664 Standard Escape 664 Optional MTPLM
Roof Profile
High Line Low Line Low Line
Engine
130 MJT (2.3L) 130 MJT (2.3L) Auto 130 MJT (2.3L) 130 MJT (2.3L) Auto 130 MJT (2.3L) 130 MJT (2.3L) Auto
Engine Capacity
2287cc 2287cc 2287cc 2287cc 2287cc 2287cc
Max Power
96kW @ 3600rpm 96kW @ 3600rpm 96kW @ 3600rpm 96kW @ 3600rpm 96kW @ 3600rpm 96kW @ 3600rpm
Torque
320Nm @ 1800rpm 320Nm @ 1800rpm 320Nm @ 1800rpm 320Nm @ 1800rpm 320Nm @ 1800rpm 320Nm @ 1800rpm
Chassis
MWB Fiat Chassis MLWB Fiat Chassis MLWB Fiat Chassis
Wheel base
3.45m/11'4" 3.80m/12'6" 3.80m/12'6"
Designated Passenger Seats
3 3 3
Berths (sleeping positions)
5 4 4
Overall Length (no ladder)
6.30m/20'8" 6.72m/22'1" 6.72m/22'1"
Overall Width (mirrors folded)
2.24m/7'4" 2.24m/7'4" 2.24m/7'4"
Overall Height (excludes TV aerial and roof rack)
2.94m/9'8" 2.85m/9'4" 2.85m/9'4"
Maximum Technical Permissible Laden Mass (A)
3300kg 3300kg 3500kg 3650kg
Mass in Running Order (B)†
2899kg 2916kg 2919kg 2936kg 2919kg 2936kg
Maximum User Payload (A-B)
401kg 384kg 581kg 564kg 731kg 714kg
Unladen Weight
2674kg 2691kg 2694kg 2711kg 2694kg 2711kg
Essential Habitation Equipment
9kg 9kg 9kg
Thermal Insulation Grade
Two Two Two
Bed Sizes
Front Double
1.89m x 1.22m / 6'2" x 4'0" 2.08m x 1.24/0.93m / 6'10" x 4'1"/3'1"
Front Nearside Single
1.85m x 0.68m / 6'1" x 2'3"
Front Offside Single
1.89m x 0.92m / 6'2" x 3'0"
Rear Double
1.85m x 1.25m / 6'1" x 4'1"
Rear Nearside Single
Rear Offside Single
Rear Bunk (Upper)
Rear Bunk (Lower)
Overcab Bed
2.08m x 1.37m / 6'10" x 4'6"
